Samsung UE32F6100AW Serviceanleitung Seite 49

Level Loc. Part Code
...4 AD480 2203-007370
...4 AD480 2203-007513
...4 2703-000158
...4 2703-001209
...4 2703-002332
...4 2703-003149
...4 2703-003343
...4 2703-003407
...4 2703-003930
...4 2801-003773
...4 3301-002039
...4 3701-001861
...4 3707-001106
...4 3708-003073
...4 3709-001712
...4 EH01 3711-007742
...4 EH01 3711-008131
...4 3722-003457
...4 3722-003546
...4 3722-003655
...4 3722-003667
...4 ET01 BN40-00256A
...4 BN41-01954A
...4 BN97-06502F
....5 1107-002226
...4 BN97-06502K
....5 1107-002049
....5 BN46-00316E
....5 BN46-00323A
..3 BN97-07120A
...4 BN46-00328A
1 BN92-11712M
.2 BH68-00662A
.2 BN69-08511A
.2 BN69-08543G
1 BN92-11718A
.2 6902-000379
.2 6922-000003
.2 T0214 AA61-20285C
.2 BN69-03982M
Copyright© 1995-2013 SAMSUNG. All rights reserved.
Description & Specification
C-CER,CHIP;10000nF,10%,10V,X7R,TP,2012
C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0
INDUCTOR-SMD;1uH,10%,2012,.4Ohm,50mA,45,
INDUCTOR-SMD;1.2uH,10%,1608,.8Ohm,25mA,3
INDUCTOR-SMD;330nH,5%,1608,3Ohm,100mA,32
INDUCTOR-SMD;2.2uH,20%,5050,0.055Ohm,300
INDUCTOR-SMD;2.2uH,20%,2520,0.104Ohm,130
INDUCTOR-SMD;120nH,5%,1608,1.2Ohm,300mA,
INDUCTOR-SMD;4.7uH,20%,5050,0.072Ohm,245
CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh
BEAD-SMD;26ohm,1608,TP
CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-A,AU
CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF
CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N
CONNECTOR-CARD SLOT;68P,1.27mm,ANGLE,AU,
HEADER-BOARD TO CABLE;BOX,20P,2R,2mm,ANG
HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN
JACK-USB;4P/1C,NI,BLK,A
JACK-PIN;5P+Screw hole,NI+SN,G,Y/BLU/RED
JACK-SCART;21P,SN,BLK
JACK-PHONE;1P/7C,AU/NI,BLK,STRAIGHT
TUNER;DTOS40EIH035A,DTOS40EIH035A,DVB-TC
PCB MAIN;NT13 ISDB-T,FR-4,4,1.2T,158*193
ASSY MICOM-SUB;T-NVTFAEUS,NT13 EU (F4500
IC-NOR FLASH;W25Q40CLSSIP,4Mbit,SOIC,8P,
ASSY MICOM;T-NVTF6DEUC,NT13 EU4 (F4500/F
IC-NAND FLASH;K9F1G08U0D-SCB0,1Gbit,128M
S/W-E-MANUAL;NOVATEK13,EU4,XC,XN,ZF,ZG,Z
S/W MICOM;T-NVTF6DEUC-XXXX,2012.11.19
ASSY DRM;EUROPE
KEY CODE;KEY CODE-CERTIFI:CI+,TV,NT13,eu
ASSY BOX;UF6K
LABEL BOX-00;ALL MODEL,paper,60,110,WHT,
BOX-01,SET,IN;55UF64000-QS,CB,C-01,DW1,Y
BOX-01,SET;55UF6100-QS,CB,C-03,DW3,YEL,W
ASSY P/MATERIAL;UF6000 46
BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0
BAND PP;PP,T0.8,W18,L1650M,TRP,DA69-9014
HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g
PAD PACKING-EDGE;EDGE,PAPER,-,T5,W120,L2
Exploded Views and Parts List
Qty. SA/SNA
2 SA
15 SA
3 SA
3 SA
1 SA
2 SA
1 SNA
2 SA
5 SA
1 SA
53 SA
2 SA
1 SA
1 SNA
1 SA
2 SA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
4 SNA
1 SNA
13
