Samsung UE32F6100AW Serviceanleitung Seite 41

Level Loc. Part Code
...4 BN61-09304A
...4 BN63-10451A
...4 BN63-10916A
...4 BN63-10917A
...4 BN96-25103A
....5 BN60-00748N
....5 BN61-08723A
...4 BN96-25114A
....5 BN60-00744A
....5 BN60-00748P
....5 BN61-08724A
...4 BN96-25115A
....5 BN60-00748Q
....5 BN60-00748R
....5 BN61-08725A
...4 BN96-25291A
....5 6001-002757
....5 6001-003005
....5 BN02-00040C
....5 BN02-00043D
....5 BN61-08161A
.....6 0103-009493
....5 BN61-08815A
.....6 0103-005041
....5 BN61-09049A
....5 BN61-09101A
.....6 0103-009930
....5 BN62-00338E
....5 CC02 BN64-02202A
....5 BN96-25338A
....5 GL63-00014A
...4 BN96-25312A
...4 BN96-25313A
..3 TCON BN95-00864A
...4 BN62-00366A
...4 BN97-07277A
....5 0202-001899
....5 DS01A 0401-001192
....5 0403-001172
....5 0404-001640
Copyright© 1995-2013 SAMSUNG. All rights reserved.
Description & Specification
SUPPORT-PLATE;Y13 SLIM / VNB,PC,WHT + CL
SHEET-REFLECTOR;UXJP175,SHEET*,0.175,123
SHEET-DIFFUSER;CH273M_55inch_NNB,SHEET*,
SHEET-DBEF;DBEF D2 400_55inch NNB,SHEET*
ASSY FRAME P-MOLD MIDDLE(U);Y13 F-LED Sl
SPACER-PANEL (UP);13 SF-LED 55,SILICON+T
FRAME-MOLD MIDDLE(U);Y13 F-LED Slim 55",
ASSY FRAME P-MOLD MIDDLE(D);Y13 F-LED Sl
SPACER-RUBBER;Y13 F-LED SLIM,SH-0140U+AT
SPACER-PANEL (DOWN);13 SF-LED 55,SILICON
FRAME-MOLD MIDDLE(D);Y13 F-LED Slim 55",
ASSY FRAME P-MOLD MIDDLE(LR);Y13 F-LED S
SPACER-PANEL (LR);13 SF-LED 55,SILICON+T
SPACER-PANEL (CORNER);13 SF-LED 55,SILIC
FRAME-MOLD MIDDLE(LR);Y13 F-LED Slim 55"
ASSY MISC P-CHASSIS BOTTOM;Y13 SF-LED 55
SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1
SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1
TAPE DOUBLE FACE-D-PLATE;F-LED ALL,MKT50
TAPE ETC-SHEET FIXING;Y13 slim F-LED,PET
HOLDER-LED-PCB;Direct-LED,PC,white
RESIN-PC;LH-1070W,W92853,WT0107,V-2
HOLDER-SOURCE PCB;SLIM-FLED,ABS+PC,BLK,V
RESIN-PC;FR3200TV,901408,BK0008,1.2mm V-
BRACKET-WALL MOUNT;Y13 ALL Model,SPCC,T1
SUPPORT-SOURCE PCB;SF-LED,ABS+PC,V0,GRAY
RESIN-PC ABS;NH-1017SG,GRAY,GY0275,V0
INSULATION CABI-PD BOARD;Y13 SF-LED 39"~
CHASSIS-BOTTOM;Y13 F-LED 55,EGI-SECC,T0.
ASSY BOARD P-D-LED INTERFACE;55inch Slim
SHIELD-EMI GASKET DTB-H390V/XEE;DTB-H390
ASSY MISC P-LED BAR;55inch Slim Direct L
ASSY MISC P-LED BAR;55inch Slim Direct L
ASSY T CON;LSF550HJ02,55 FHD 120 NNB
HEAT SINK-PS;F6000,A1050,ANODIZING,80*61
ASSY SMD;BN95-00864A
SOLDER-CREAM;M705-GRN360-K2-VT,25-36um,S
DIODE-SWITCHING;MMBD7000LT1,100V,200mA,S
DIODE-ZENER;UDZ6.8B,6.65-6.93V,200MW,SOD
DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,SOD
Exploded Views and Parts List
Qty. SA/SNA
16 SNA
1 SNA
1 SNA
1 SNA
1 SNA
2 SNA
1 SNA
1 SNA
1 SNA
2 SNA
1 SNA
2 SNA
2 SNA
2 SNA
2 SNA
1 SNA
1 SA
4 SNA
2 SNA
2 SNA
2 SNA
2 SNA
4 SNA
6 SNA
4 SNA
8 SNA
12 SNA
1 SNA
1 SNA
1 SNA
2 SNA
10 SNA
10 SNA
1 SA
1 SNA
1 SNA
2 SNA
2 SA
1 SNA
2 SA
5
