Samsung UE32F6100AW Serviceanleitung Seite 45

Level Loc. Part Code
....5 6302-001290
....5 BN41-01939B
....5 BN97-07139A
.....6 1107-002224
..3 TC-OC BN96-24429A
..3 BN96-24848A
...4 BN81-07434A
...4 BN81-07466A
...4 BN81-07883A
...4 BN81-07897A
...4 BN81-07908A
...4 BN81-07933B
...4 BN81-07934B
...4 BN81-07943A
..3 TC01A BN96-25290A
...4 BN60-00667A
...4 BN60-00701J
...4 BN60-00701K
...4 BN60-00715A
...4 BN63-07556U
...4 BN63-10945B
...4 AC157 BN64-02196A
..3 BN96-26729A
...4 BN62-00379G
..3 BN96-26729B
...4 BN02-00152A
...4 BN62-00379H
...4 BN63-10492A
1 M0017 BN91-10279Z
.2 M0014 BN94-06165Z
..3 BN61-09059A
...4 0103-004628
..3 BN62-00368A
..3 BN97-07019F
...4 0202-001899
...4 DS01A 0401-001056
...4 0403-001783
...4 0403-001785
...4 0403-001797
...4 0404-001404
Copyright© 1995-2013 SAMSUNG. All rights reserved.
Description & Specification
GASKET;SMR-TS-4-4.5-3,4.0mm,Ni+Au+SUS+Mg
PCB MAIN;2013 FHD 120Hz/240Hz,FR-4,4,1.2
ASSY MICOM;F55A1F012,2013.02.05,EEPROM
IC-FLASH MEMORY;W25X40CLSSIG,4Mbit,SOP,8
ASSY CABLE P-FFC;E6K(3D), E7K(3D),FFC,57
ASSY OPEN CELL;LSF550HJ02-A,8bit,55 INCH
A/S-ADHESIVE-A.C.F(CP);ADHESIVE-A.C.F,1-
A/S-IC DRIVER GATE;IC DRIVER GATE,2-IC D
A/S-IC DRIVER SOURCE;IC DRIVER SOURCE,13
A/S-POLARIZER-C/F;8-POLARIZER-C/F
A/S-POLARIZER-TFT;POLARIZER-TFT
A/S-ASSY PCB-SOURCE LEFT;ASSY PCB-SOURCE
A/S-ASSY PCB-SOURCE RIGHT;ASSY PCB-SOURC
A/S-ADHESIVE-A.C.F(TP500B);ADHESIVE-A.C.
ASSY MISC P-CHASSIS TOP;Y13 SF-LED 55(6.
SPACER-GASKET;Y13 SF-LED,GASKET(FG200A),
SPACER-TOP,UD;Y13 Slim F-LED 55,GASKET*,
SPACER-TOP,LR;Y13 Slim F-LED 55,GASKET*,
SPACER-TOP,CORNER;Y13 Slim F-LED,GASKET*
COVER-SHEET;F-LED,urethane,T0.068,W18,10
COVER-SHEET;Y13 SF-LED,PO-SHEET,T0.068,W
CHASSIS-TOP;Y13 F-LED Slim 55",PC+ABS+G/
ASSY MISC P-SHIELD SOURCE,PCB;Y13 SF-LED
INSULATION CABI-SHILED FHD L;Y13 SLIM 55
ASSY MISC P-SHIELD SOURCE,PCB_R;Y13 SF-L
TAPE ETC-SHEET FIXING;Y13 Slim F-LED,PET
INSULATION CABI-SHILED FHD R;Y13 SF-LED
SHIELD-SOURCE PCB;Y13 SF-LED 55",EGI-SEC
ASSY CHASSIS;F6100,55,XC
ASSY PCB MAIN;F6100,55,XC
HOLDER-SIDE AV;UF6100,HIPS,BK0020,HB,EO/
RESIN-HIPS;HF-1690H,K2901,BK0020,1.5mm H
PAD GAP;F5000,SILICON,40*40 mm,6.5,Light
ASSY SMD;F6100
SOLDER-CREAM;M705-GRN360-K2-VT,25-36um,S
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO
DIODE-ZENER;NZH5V1B,4.94/5.2V,500mW,SOD-
DIODE-ZENER;NZH3V0B,2.85/3.15V,500mW,SOD
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
Exploded Views and Parts List
Qty. SA/SNA
4 SNA
1 SNA
1 SNA
1 SNA
2 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SA
6 SNA
2 SNA
2 SNA
4 SNA
1 SNA
3 SNA
1 SNA
1 SNA
1 SNA
1 SNA
3 SNA
1 SNA
1 SNA
1 SNA
1 SA
1 SNA
13 SNA
1 SNA
1 SNA
8 SNA
1 SA
4 SNA
1 SA
1 SNA
1 SA
9
