Samsung UE32F6100AW Serviceanleitung Seite 44

Exploded Views and Parts List
Level Loc. Part Code
....5 2007-008596
....5 AD480 2203-000257
....5 AD480 2203-000489
....5 AD480 2203-000995
....5 AD480 2203-001126
....5 AD480 2203-001697
....5 AD480 2203-001851
....5 AD480 2203-002711
....5 AD480 2203-002982
....5 AD480 2203-005138
....5 AD480 2203-005249
....5 AD480 2203-005344
....5 AD480 2203-005918
....5 AD480 2203-006048
....5 AD480 2203-006158
....5 AD480 2203-006320
....5 AD480 2203-006348
....5 AD480 2203-006427
....5 AD480 2203-006474
....5 AD480 2203-006562
....5 AD480 2203-006698
....5 AD480 2203-006890
....5 AD480 2203-006960
....5 AD480 2203-007240
....5 AD480 2203-007270
....5 AD480 2203-007306
....5 2409-001118
....5 2409-001240
....5 2703-003747
....5 2703-003803
....5 2703-003862
....5 2703-003867
....5 2703-003937
....5 2703-004199
....5 2801-003954
....5 3301-002039
....5 3601-001386
....5 3708-002157
....5 EH01 3711-005601
....5 EH01 3711-005925
8
Description & Specification
R-CHIP;0.1ohm,1%,1/4W,TP,3216
C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005
C-CER,CHIP;0.047nF,5%,50V,C0G,TP,1005
C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1608
C-CER,CHIP;0.082nF,5%,50V,NP0,TP,1608
C-CER,CHIP;0.016nF,5%,50V,NP0,TP,1608
C-CER,CHIP;100nF,10%,25V,X7R,TP,1608
C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1005
C-CER,CHIP;1.8nF,10%,50V,X7R,TP,1005
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,0.5T
C-CER,CHIP;1000nF,10%,6.3V,X7R,TP,1608
C-CER,CHIP;100nF,10%,10V,X7R,TP,1005
C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,0.5
C-CER,CHIP;2200nF,10%,16V,X7R,TP,2012
C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0.
C-CER,CHIP;4700nF,10%,16V,X5R,TP,2012
C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,2012
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
C-CER,CHIP;1000nF,10%,25V,X7R,TP,1608,0.
C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608
C-CER,CHIP;1000nF,10%,50V,X7R,TP,2012
C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608,
C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0
C-CER,CHIP;10000nF,10%,25V,X5R,TP,2012,1
C-POLYMER ,CHIP;47uF,20%,10V,WT,TP,3.5X2
C-ORGANIC,SMD;33uF,20%,25V,LR,TP,7343(1.
INDUCTOR-SMD;22uH,20%,6060,0.135ohm,1300
INDUCTOR-SMD;4.7uH,20%,6060,0.031ohm,270
INDUCTOR-SMD;10uH,20%,6060,0.065ohm,1900
INDUCTOR-SMD;22uH,20%,4040,1.8T,0.29Ohm,
INDUCTOR-SMD;1uH,20%,7.0x6.47x3.0mm,0.00
INDUCTOR-SMD;10uH,20%,7066,2.2mm,0.101Oh
CRYSTAL-SMD;27MHz,30ppm,28-AAN,16pF,50oh
BEAD-SMD;26ohm,1608,TP
FUSE-SURFACE MOUNT;125V,5A,FAST-ACTING,C
CONNECTOR-FPC/FFC/PIC;80P,0.5mm,SMD-A,AU
HEADER-BOARD TO CABLE;BOX,8P,1R,2mm,SMD-
HEADER-BOARD TO CABLE;BOX,51P,1R,0.5mm,S
Copyright© 1995-2013 SAMSUNG. All rights reserved.
Qty. SA/SNA
1 SC
1 SA
3 SA
2 SA
1 SNA
2 SA
2 SNA
3 SA
1 SA
3 SA
12 SNA
3 SNA
2 SNA
9 SA
61 SNA
1 SNA
3 SA
1 SA
6 SA
2 SNA
12 SNA
8 SNA
1 SNA
3 SA
13 SNA
31 SNA
1 SA
1 SA
2 SA
1 SA
1 SA
1 SA
1 SA
1 SNA
1 SA
24 SA
1 SA
2 SNA
1 SA
1 SA
