6.4

Preparing the measurement

Introductory information
The language selected by the user when installing the software is also offered by the software as
the standard language.
If you want to use a language different from the one selected when installing the software, you
can select it via the relevant icon ("selection of a language supported by the system") on the tool
bar.
Before the PCE-DFG N works in combination with the software, you must set the assigned COM
port as well as the baud rate in the device as well as in the software. This has to be done only
once.
Note:
It is important that the baud rate is the same in the PCE-DFG N and in the software.
The COM port and the baud rate for the software can be set in the Settings window for
static device data.
In addition to the connection data, further settings like the date and time format and the number
of decimal places shown can be set in this window.
Establish connection to the PCE-DFG N
The connection to the PCE-DFG N can be established by clicking on the relevant icon („Connect
with the PCE-DFG N").
Select a language supported by the system
Show information window
Close program
