4. Putting into Operation

Wrong
OK
Lab Master-aw multi channel
displaywith 2 Lab Partner-aw

5. Chamber settings

6. Standard accessories

10
Switch ON the Lab MASTER-aw unit.
-> Select the desired channel number of the connected
Lab PARTNER-aw
For selecting please see below "3. Menue settings"
Remarks :
A device number can be allocated using the software set up to
uniquely identify the unit.
Attention!
No two units may be allocated the same number in a network!!
The Lab MASTER-aw and subsequently all connected Lab PARTNER-
aw units are powered on. An acoustic signal and the standard display
on the Lab Partner LCD confirm when they are ready for use (if the
Lab MASTER-aw fails to operate any of the Lab PARTNER-aw units,
the display „Waiting for Master" appears on the respective
Lab PARTNER-aw). This error can arise due to missing or incorrect
cabling to the Lab MASTER-aw or an incorrectly or duplicated
Lab PARTNER-aw device number.
Note:
If there are several user profiles entered in the Lab MASTER-aw
system the Lab PARTNER-aw can only be operated by one user who
is logged in.
Please check and make sure that on a system of Lab MASTER /
PARTNER-aw there can be only one Lab MASTER as main unit. It is
strictly forbidden to connect two Lab MASTER-aw by the communica-
tion cable.
All chamber settings can be set separately for each measuring
chamber (0 ... 9) on the Lab MASTER-aw. For more details please
consult the „chamber settings" section of the Lab MASTER-aw opera-
ting manual.
• 50 sample cups
• Operating instructions ( Lab MASTER / PARTNER-aw)
• Power and communication cables, with 1.8m length, for con-
nection between Lab MASTER and Lab PARTNER.
