Features
• You can use the camera with 12V/200mA
• The camera utilizes a CCD image sensor giving a high quality picture.
• The camera automatically adjusts the picture quality with changing in light.
• Water-resistant housing
• Operates over a wide temperature range
Camera input connector pin description
Camera installation
Attach the supplied mounting
A.
bracket to the vehicle.
Adjust the angle of the camera
and fasten the screws firmly.
Specifications
• Image
• Picture elements
• Image size
• Lens
• View angle
• Synchronization
• Horizontal resolution 330TV lines
• Required illumination 1.0 Lux
• Signal to noise ratio
• Power supply
• Power consumption 3.0W
• Oprating temp.
• Weight
• Dimensions
• Supplied Acc'y
Design and specifications are subject to change without notice.
Pin No.
1
2
3
4
5
Interline transfer type CCD
NTSC : 270.000 pixels
1/3 Inch
Maximum aperture F=2.0
78º (Vertical), 104º (Horizontal), 130º (Diagonal)
International
Better than 47 dB (at AGC off )
DC 12V
-30°C to +50°C (-22°F to +122°F)
0.5kg
91(W) x 53(H) x 78(D)mm
3.6(W) x 2.1(H) x 3.1(D) Inch
Ø5 x 16L Stainless screw
HEX M5XH5 Stainless
W/washer Ø 5 x 16L Stainless screw
W/washer Ø 4 x 10L Stainless screw
Camera Bracket
L-wrench 3mm
Sunshield
Description
Video Output
Tilt Control Power DC 9V
Audio Output
Plus DC 12V
Ground
B.
PAL : 320.000 pixels
(4)
(4)
(4)
(4)
(1)
(1)
(1)
white
blue
red
yellow
black
Run the cable from the monitor
to the camera
GB
