(ill. 7)
Legen Sie das Kabel in den entspre-
chenden Querschnittsbereich� Achten
Sie darauf, dass das Kabel am Längen-
anschlag ansteht�
7
(ill. 8)
Drücken Sie die Zangengriffe ganz
zusammen�
8
(ill. 9)
Führen Sie die Abisolierzange in die
Ausgangsposition zurück und und
entnehmen Sie das abisolierte Kabel�
9
(ill. 7)
Insert the cable in the appropriate
cross-section range� Make sure that
the cable rests against the length
gauge stop�
(ill. 8)
Press the handles of the pliers fully
together�
(ill. 9)
Return the stripping pliers to the start-
ing position and take out the stripped
cable�
5 / 8
