Read the operating instructions and the enclosed brochure
!
„Guarantee and additional notices" completely. Follow the
instructions they contain. Safely keep these documents for
future reference.
Compact laser distance meter for measuring length,
area and volume indoors
g e b
a
g
j
h
g
1.
2.
4.
6.
DistanceMaster Home
DISPLAY:
a
f
i b
c
d
d
e
c
f
g
h
i
j
KEYPAD:
1.
2.
3.
3.
5.
4.
5.
6.
7.
7.
Measurement point (reference)
rear / pin / front
Display length / area / area addition /
volume / Pythagoras 1 / Pythagoras 2
Measurement values / Measurement
results Unit m / ft / inch / _' _"
Intermediate values / min/max values
The bar diagram shows how well
suited the refl ection surface is for
measurement.This is particularly
useful for measuring over long
distances, dark surfaces or bright
ambient light.
Battery symbol
min/max continuous measurement
Malfunction / service required
Memory
Reference measurement
ON / Measure /
min/max continuous measurement
length, area, area addition, volume,
Pythagoras, Reference measurement
Measurement point (reference)
rear / pin / front
addition of lengths, areas, volumes
subtraction of lengths, areas, volumes
Display lighting ON/OFF /
Unit of measure m / ft / inch / _' _"
OFF / delete last measurement values
