7.1. Frequency Measurement
Frequency Span
Frequency Range:
Setting Modes:
Maximum Span:
Minimum Span:
Setting Resolution:
Setting Accuracy:
Reference Frequency Accuracy
Initial Accuracy:
Stability:
Ageing:
Phase Noise
Phase Noise:
Resolution Bandwidth
RBW:
Video Filtering:
Frequency Markers
Number of Markers:
Marker Resolution:
Marker Accuracy:
Frequency Readout:
7.2. Amplitude Measurement
Amplitude Range
Display Range:
Reference Level:
Amplitude Accuracy
Ref. Level Accuracy:
Level Flatness:
Amplitude Linearity:
8
150 kHz to 1300 MHz (in one range)
Centre frequency plus Span, or Start frequency plus Stop frequency
1299.85 MHz (150 kHz to 1300 MHz)
320 kHz, or Zero Span with demodulation
1 kHz at any frequency
Reference Frequency Accuracy for Start, Stop & Centre (Zero-Span) frequencies
Better than ± 10 ppm at 20
Better than ± 10 ppm over 10
Better than ± 3 ppm per year
Typically -100dBc/Hz at 100kHz offset at 500MHz
Selectable as 280 kHz or 15 kHz
Selectable independently of RBW setting
One, Two, or None
0.1 kHz at all frequencies
th
1/320
of Frequency Span ± 0.1kHz + Reference Frequency Accuracy
The frequencies at the marker points and frequency difference are displayed
simultaneously
80 dB
Selectable as -20 dBm or 0dBm
Better than ± 1 dB at 50MHz at 10dB below reference level (20
Better than ± 1.5 dB relative to 50MHz over 500kHz to 1300MHz
Better than ± 1 dB over 50dB range down from reference level
7. Specification
o
C
o
o
C to 30
C
o
o
C ± 5
C)
