7.9. Power Sources
AC Line Operation/Charging
The PSA1301T can be operated from mains power using the AC power adaptor provided by TTi. This
powers and recharges both the PSA1301 Spectrum Analyzer and the Palm T
AC Adaptor/Charger
Input Voltage Range:
Battery Operation
The PSA1301 and the Palm T
turned off automatically whenever the PSAnalyzer program is exited, or when the Palm T
PSA1301 Spectrum Analyzer
Battery Type:
Battery Life:
Recharge Time:
Palm T|X
Battery Type:
Battery Life:
Recharge Time:
Auto Sleep Mode
To conserve battery life, the system can be set to automatically switch into sleep mode after a defined
time from the last key press. This can be set between 5 mins and 60 mins (or never).
7.10. Mechanical
Size:
Weight:
Tilt Stand:
7.11. Environmental and Safety
Operating Range:
Storage Range:
Environmental:
Electrical Safety:
EMC:
100V to 240V nominal 50Hz/60Hz. Interchangeable plus for UK, Euro, USA
and Australia are supplied.
|
X contain their own internal rechargeable battery packs. The PSA1301 is
Ni-Mh 3.6V 700mA-hr (3 x AAA cell)
> 5 hours continuous operation
< 3 hours from fully discharged
Li-ion 3V 1050mA-hr
Typically 4 hours continuous operation (depending on backlight brightness)
< 4 hours from fully discharged
170mm high x 97mm wide x 47mm deep (including feet)
495 grms total including Palm T|X.
Built-in tilt stand for bench use which angles the unit at approximately 25
degrees to the horizontal and can alternatively be used as a hook mount.
o
o
+5
C to + 40
C, 20% to 80% RH.
o
o
-10
C to +50
C
Indoor use at altitudes to 2000m, Pollution Degree 2.
Complies with EN61010-1.
Complies with EN61326.
|
X simultaneously.
|
X is turned off.
11
