7.6. Display
Display Type:
Trace Area:
Raster:
Displayed Points:
Live Trace:
Reference Trace:
Resolution Modes:
* In low resolution mode the trace area becomes 150 x 160 points where each point is a block of 4 pixels.
Only 160 sweep points are displayed. This mode is useful in situations where the display could
otherwise be difficult to see - e.g. when the instrument cannot be viewed at an optimum distance.
7.7. Memory Storage
Memory Type:
Store Trace:
Recall Trace:
Store Set-up:
Recall Set-up:
Store Screen:
7.8. Connectors
RF Input Connector:
Power Connector:
USB Connector:
Audio Connector:
10
3.7 inch (9.4 cm) transflective backlit TFT LCD, 480 x 320 pixels total, 16 bit
colour, touch screen.
300 x 320 pixels (high resolution mode).
8 x 10 divisions light grey Raster. Selectable as fully on, horizontal lines only, or
off).
320 points per sweep (peak detected).
Dot-joined trace from current or held sweep. Selectable on or off.
Stored trace either recalled from memory or copied directly from live trace.
Selectable on or off.
Selectable as High Resolution or Low Resolution *
Non volatile Flash memory using removable SD or MMC memory cards.
Any number of traces can be stored under either default file names or user
entered file names. Traces are stored as tables of amplitude versus frequency
and can be imported into other programs, as well as being recalled to the
screen.
Recalls any stored trace to the reference trace of the display.
Any number of instrument set-ups can be stored under either default file names
or user entered file names. All settings of the instrument are saved.
Recalls any stored set-up, overwriting the existing settings of the instrument.
This function copies the whole screen area to memory as a bit-map. Any
number of screens can be stored under either default file names or user entered
file names. Screen bit-maps can be viewed using the "Media" application of the
|
Palm T
X, or transferred to a PC for printing.
Standard SMA connector.
1.3 mm dc power socket (centre positive) for 5.2V/1A external AC power
adaptor/charger as supplied by TTi.
Mini USB connector (5 pin mini B) which provides direct access to the USB port
|
of the Palm T
X.
3.5 mm jack socket for demodulated audio out (accepts mono or stereo plugs).
