R6106HF
For parkflight or indoor use airplanes.
For electric helicopters up to 1000mm of main rotor diameter.
R6106HFC
For small size airplanes such as wing span of up to around 1300mm.
For carbon fuse such as non powered sail planes.
Thank you for purchasing the R 6 1 0 6 H F ,
R6106HFC FASST receiver. These models have
two(2) operation mode as shown below.
Normal mode/High Speed mode
The "Normal mode" accepts any type of servos
or the peripherals as the frame rate of the output
is 16ms. The "High Speed mode" only accept
the digital servos, including BLS series, and
most peripheral equipments such as the gyros or
Antenna installation for carbon fuse
(R6106HFC)
WARNING
The antenna portion of 30mm tip
must be fully exposed.
• Please make sure that the exposed portion won't
be slided back in the fuse by the wind pressure
or other force during the flight session.
Antenna
Usage condition on "High
Usage precautions about the power source
Speed mode"
We do not recommend to use the power source of less
CAUTION
than 4.0V but if to use the lower voltage source please
keep in mind the condition shown below.
T h e " H i g h S p e e d m o d e "
• Fail Safe function MUST be in "off" since the battery f/s will
accept the digital servos only
disturb the normal operation.
or most type of peripherals.
• Please make sure that the full loaded condition of the ESC
• If any analog servos connected to these
and the servos won't disturb the receiver operation before
output as it will cause malfunction.
start flight.
Please check the peripherals if there's
This is very important since the receiver will stop operation
any malfunction with whole stick lever
when the supply voltage drops to around 3.0V.
throw. If any malfunction occur please
• Please be sure that the ESC or servos can keep flawless
change the operation mode to "Normal
operation till such a lower voltage.
mode."
If the servo's maximum voltage rating is less than 8.5V,
the power source voltage must not exceed the servo's
rating.
brushless ESCs. The frame rate of the outputs is
8ms.
The R6106HF, R6106HFC are compatible with
the FASST transmitters as shown below.
T6EX-2.4GHz, T7C-2.4GHz, TM7,
TM8
, TM10
(on 7ch mode)
(on 7ch mode)
T10CG
TM14
(on 7ch mode),
(on 7ch mode)
LED
Antenna
Link/Mode Switch
R6106HF
LED
Link/Mode Switch
R6106HFC
Operation Mode Select
The operation mode is on "Normal mode" from
factory shipping. When to change the mode,
please follow the steps shown below.
1
Turn off the receiver.
2
Press and hold the link/mode switch and
turn on the receiver. Keep the switch hold
more than one(1) second. The LED starts
flashing with the current status.
3
Release the switch.
4
Turn off the receiver.
By doing this step, the mode can switch over
between two(2) modes.
,
Turn on the receiver.
0 sec.
1 sec.
Press and Hold time
0 to 1 sec.
More than 1 sec.
To change the mode between
（Function）
No function
Normal and High Speed
Showing the CURRENT
Solid as the mode changed.
mode with blink.
Red Solid = Normal
Red Blink = Normal
Green/Red Solid = High
（LED Status）
Green/Red Blink =
Speed
High Speed
(Become Red after one (1)
second)
Please check the operation mode by observing
the LED when turning on the receiver. If possible
there's no FASST transmitter turned on around you
in order to make firmer check.
When turn on the receiver, the LED will be;
• Red when on "Normal mode"
• Green and Red (makes Orange) when on "High
Speed mode". (After two(2) seconds, change to Red.)
If there are some FASST transmitter turned on
around the receiver, the LED may show the above
status for a brief moment then changed to the
status indication as shown in the "LED indication"
table.
LED Indication
Green
Red
Status
Solid
Solid
Initializing
Off
Solid
No signal reception
Solid
Off
Receiving signals
Blink
Off
Receiving signals but ID is unmatched
Link to the transmitter
1
Press and hold the Link/Mode switch more
than two(2) seconds.
FUTABA CORPORATION
Makuhari Techno Garden Bldg., B6F 1-3 Nakase, Mihama-ku, Chiba 261-8555, Japan
1M23N17419
Re-adjust the F/S position (only
for TM-7/TM-8)
1
Press and hold the Link/Mode switch
between one(1) and two(2) seconds.
0 sec.
1 sec.
2 sec.
0 to 1 sec.
1 to 2 sec.
Press and Hold time
To set the F/S
Re-link(ID set) and to
With TM-7, TM-8
No function
position(No re-link)
With TM-10, TM-14,
No function
6EX, 7C, etc.
WARNING
Do not perform the linking procedure
with motor's main wire is connected
or the engine is operating as it may result in
serious injury.
While the linking is done, please
cycle receiver power and check if
the receiver to be linked is really under the
control by the transmitter to be linked.
Compliance Information Statement
(for U.S.A.)
This device, trade name Futaba Corporation of
America, model number R6106HF/R6106HFC,
complies with part15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference
received, including interference that may cause
undesiredoperation.
The responsible party of this device compliance is:
Futaba Service Center
3002 N Apollo Drive Suite 1, Champaign, IL 61822 U.S.A.
TEL (217)398-8970 or E-mail: support@futaba-rc.com (Support)
TEL (217)398-0007 or E-mail: service@futaba-rc.com (Service)
R6106HF/R6106HFC Specifications
FASST-2.4GHz system 6-channel receiver
• Power requirement: 3.3V~8.5V regulated output
from ESC, etc. (*1)
• Battery F/S voltage: 3.8V
• Size: 0.85 x 1.53 x 0.48 in. (21.7 x 38.8 x 12.3 mm)
• Weight: 0.24 oz. (6.7g)/0.25 oz. (7.1g)
(*1) Be sure that when using ESC's regulated output
the capacity of the ESC must meet your usage
condition.
Phone: (043) 296-5118 Facsimile: (043) 296-5124
©FUTABA CORPORATION
2009, 05
More than 2 sec.
set the F/S position
Re-link(ID set)
(1)
