Specifications - Quer KOM0944 Bedienungsanleitung

Recording via External Microphone:
Connect a storage device (USB/memory card) and press REC/DEL button to
start recording (please note recording time depends on the storage capacity).
During recording, set the "ECHO" knob to the minimum. Make sure the
microphone is located in a proper distance away from the speaker to prevent
any howl-round or noise.
Notes: This product starts recording from the time as displayed on the display.
FM RADIO
Before first use of the radio on this device, run an automatic station search.
Repeatedly press MODE/SHIFT button to enable FM mode. Press and hold
button to run automatic programming. Found stations will be saved on preset
stations list.
Once the automatic station search is done, press
next station on the preset list.
BLUETOOTH PAIRING MODE
1. Turn on the device.
2. Press the MODE/SHIFT button to enter Bluetooth mode; the screen will
display "BLUE".
3. Switch on the Bluetooth on your external device and search for other
available Bluetooth devices.
4. Pair with this device "KOM0944": Insert default password "0000" if necessary.
5. The speaker will prompt the successful pairing between the devices.
6. Play music directly from your external device.

SPECIFICATIONS

• Output power: 20 W + 5 W
• Frequency response: 100 Hz – 20 kHz
• Speaker: 6,5" + 2"
• Impedance: 4 Ω
• Disortion: ≤ 1%
• S/N ratio: ≥ 85 dB
• Bluetooth 3.0
• Bluetooth range: up to 10 m
• FM radio (60 preset station memory)
• Karaoke function
• Inputs/Outputs:
○ Line input (3,5 mm jack)
Owner's manual
or to go to previous /
EN
11
