Operating instructions
Raspberry Pi USB to SD 3.0 (SDXC) Converter
®
Item no. 1490510

Intended use

The product adds another SD card slot to your Raspberry Pi
version 3.0 (SDXC).
It is intended for connecting to a USB port.
In addition, you can also operate it on a computer with Windows
installation is not necessary.
Power is supplied and data is transferred via USB (micro USB2.0 port (USB_M) or 5-pin con-
nector (USB_P)).
For safety and approval reasons, you may not convert and/or alter the product. If you use the
product for purposes other than those described above, the product may be damaged. Moreo-
ver, the improper use involves risks such as short-circuits, fire, electric shocks, etc. Please read
the operating instructions carefully and do not discard them. If you pass the product on to a third
party, please hand over these operating instructions as well.
Observe all safety information and other information contained in these operating instructions.
This product complies with the applicable national and European regulations. All names of
companies and products are the trademarks of the respective owners. All rights reserved.

Package Contents

• USB to SD 3.0 SDXC converter board
• Screw set with spacers
• Micro USB cable, approx. 0.15 m
• Operating Instructions
Up-to-date operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or scan the
QR code. Follow the instructions on the website.

Explanation of Symbols

The lightning symbol inside of a triangle is used when there is a potential risk of
personal injury, such as electric shock.
An exclamation mark in a triangle indicates important instructions in this operating
manual which must be adhered to.
The arrow symbol indicates special tips and operating information.

Safety Instructions

Please read the operating instructions carefully and pay particular attention to
the safety instructions. We do not assume liability for injuries/material damag-
es resulting from failure to observe the safety instructions and the information
in these operating instructions regarding the proper handling of the product.
Furthermore, in such cases, the warranty/guarantee will be null and void.
a) General
• When you touch or connect the board, you should take the appropriate safety
precautions against static charge (e.g., ground strap, insulating support, etc.).
• The product is not a toy. Keep out of the reach of children and pets. Position the
product so it is out of the reach of children and pets.
• Do not leave the packaging material unattended, since it could become a dange-
rous plaything for children.
• The product is only suitable for dry, enclosed indoor areas. It must not get damp
or wet.
• The product must not be exposed to extreme temperatures, direct sunlight, high
dust occurrence, strong vibrations or heavy mechanical stress.
• Handle the product with care; it can be damaged by impacts, blows or falls even
from a low height.
• If you have any questions that are not answered in this manual, please contact our
technical service or another specialist.

Connection and Start-Up

, which supports SD cards of
®
Raspberry Pi
• Attach first the converter board to your Raspberry Pi
or Linux or on a MAC. A driver
®
• Insert your SD memory card into the corresponding slot of the converter. Push the memory
Connect the supplied micro-USB 2.0 cable to the micro-USB 2.0 port (USB_M) of the converter
board.
As an alternative to micro-USB 2.0 connection (USB_M) you can also use the 5-pin (USB_P)
connector. Always observe the correct allocation. You can find this information either in the
manufacturer's data sheet in English or on the board (white print next to the 5-pin connector).
Also observe the documentation of the Raspberry Pi
• The converter and the SD memory card are automatically recognised and installed. An ex-
• The green LED on the board lights up as soon as a card is inserted. During access or data
PC or MAC:
• You can also operate the converter board on a PC or MAC.
• In principle, installation and operation on a PC or MAC is the same as on the Raspberry Pi
b) Installation in a PC
• If you do not have the expertise to install the device correctly, please contact an
expert or a specialist workshop and let them carry out the installation!
• Improper installation can damage both the converter and also your computer and
all connected devices.
• Caution, lethal hazard!
Switch off the computer in which the converter board is to be installed and all con-
nected devices, and disconnect them also from the mains voltage. Pull the mains
plug! Turning off at the on/off switch is not enough!
:
®
To do this, use the screw set and the spacers provided.
Please keep in mind that not all Raspberry Pi
case, make sure especially that the converter does not cause a short circuit (e.g.,
through contact with your Raspberry Pi
card in until it clicks into place.
To remove it, push on the memory card again, then pull it out.
The memory card contacts must face the side of the board. The card can only be
inserted with the right orientation without using force.
Connect the USB plug type A to a free USB connector on your Raspberry Pi
It does not matter if your Raspberry Pi
nected. The converter board will be recognised without problem during operation.
The same is true for the memory card. It also does not matter, whether you insert
it before connecting the converter board to your Raspberry Pi
memory card is recognised without any problem like in any other card reader.
Here is the order based on the pin next to the micro-USB 2.0 port.
(VCC = 5 V/DC; D+ = data lines +; D- = data lines -; NC = no pin; GND = ground)
ternal driver is not necessary.
Depending on the operating system, it may be necessary to register or partition and format
the memory card in the operating system first.
transfer to the memory card, it starts flashing.
Please note! The converter board is not designed for installation into a PC or MAC.
However, should you nevertheless have plans to do so, observe the special safety
instructions provided in this manual.
Since the screw set is only intended for attachment to a Raspberry Pi
care in this case that the converter will not cause a short circuit (e.g., through contact
with the PC housing).
When using the 5-pin connector (USB_P), also observe the operating instructions of
your computer or main board for the correct allocation.
.
®
models have mounting holes. In this
®
)!
®
.
®
is switched on or not when the cable is con-
®
or afterwards. The
®
.
®
, take special
®
.
®
