Commissioning

MS 4 MS 7 MS 10 HS 4 HS 7 HS 10 HP 4 HP 7 HP 10
Put device switch (A) in the OFF position
Commis-
Plug in (G) mains cable
sioning
Once connected to the power supply the device is in "stand-by" mode
The right decimal point on the display (C) is lit
Put device switch (A) in the ON position
Stirring
Any set values are retained when device is switched off and even after the device is
disconnected from the power!
Set the engine speed with the operating button (E) on the right
Put device switch (A) in the ON position
Heating
Any set values are retained when device is switched off and even after the device is disconnected from the power!
Set the target temperature for the heating plate using operating button (D) [for VHP (E)]
The set value is indicated on the display (C). If energy is being supplied to the heating plate,
the red LED (B) lights up
In the stir and stand-by modes, "hot" flashes on the display after the heat has been switched off
for as long as the temperature of the set-up surface exceeds 50°C
Put device switch (A) in the OFF position, unplug contact plug
Contact-
Safety contact thermometer acc. to DIN 12878 class 2 connected with jack (H)
thermometer
Put device switch (A) in the ON position
connection
Beware the instruction manual of the contact thermometer
Important: Display (C) also indicates the target temperature of the heating plate when
the contact thermometer is connected
