Library
<SE-LVD conversion board>
3.
4.
To each drive
2.
Connect the two LVD power cables (6P) to the SE-LVD
conversion board.
Both cables have identical connector types, so that ei-
ther cable can be connected to either connector on the
SE-LVD conversion board.
3.
Connect the internal SCSI (SE) cable (50P) to the SE-LVD
conversion board.
The other end of the internal SCSI (SE) cable is con-
nected to the library SCSI board in the library.
4.
Connect the internal SCSI (LVD) cable (68P) to the drives.
The other end of the internal SCSI (LVD) cable is con-
nected to the SE-LVD conversion board.
Internal SCSI cable (approx. 1.0 m)
<Interior of library>
To SE-LVD conversion board
<With the MC-8100LU>
Internal SCSI (SE) cable
50p
6p
LVD
2.
power cable
6p
68p
Internal SCSI (LVD) cable
Terminator
Drive 4
Drive 3
Drive 2
Drive 1
Terminator
Library SCSI board
Internal SCSI
(SE) cable
SETUP
●
Set the SCSI ID of the MC-BL10U and close the door
of the CD/DVD Library.
Always turn the power of the CD/DVD Library off when
the dip switches are moved.
For the details of the default factory settings, please
refer to the section "SCSI ID No. SETTING" of the
instructions from the CD/DVD Library.
Procedure for Setting the DIP Switch
<MC-BL10U DIP switch settings on the rear panel>
1.
ID2, ID1, ID0: Setting of the SCSI ID No. of each drive.
When setting the SCSI ID No., use a number that is not
being used by other SCSI devices on the same bus.
The MC-BL10U should be used with one of the SCSI ID
No. 0 to 7. It cannot be used with No. 8 to 15.
RSV: Not available
<SCSI ID No. and DIP switch settings>
SCSI ID No.
ID2
0
OFF
1
OFF
*
2
OFF
3
OFF
4
ON
5
ON
6
ON
7
ON
Procedure for Attaching the Drive
Storage Cover of the CD/DVD Library
1.
Secure the cover with the screws that were removed.
"Procedure for Opening the Drive Storage Cover of
the CD/DVD Library" on page 3.
Procedure for Closing the CD/DVD
Library Door
1.
Close the door and lock the key cylinder.
ON
ON
OFF
1
2
3
4
(Factory setting)
Switch
ID1
ID0
OFF
OFF
OFF
ON
ON
OFF
ON
ON
OFF
OFF
OFF
ON
ON
OFF
ON
ON
*
: Factory setting.
E
