INSTALLATION FLOW
Follow the steps below for installation.
●
Install the MC-BL10U in the CD/DVD Library.
Procedure for Opening the Door of the CD/DVD Library
Procedure for Opening the Drive Storage Cover of the
CD/DVD Library
Procedure for Determining the Setup Position for the MC-BL10U
Procedure for Installing the MC-BL10U in the CD/DVD Library
●
Connect the MC-BL10U to the CD/DVD Library.
Procedure for Connecting the Cables to the Back of the MC-BL10U
●
Set the SCSI ID of the MC-BL10U and close the door of the CD/
DVD Library.
Procedure for Setting the DIP Switch
Procedure for Attaching the Drive Storage Cover of the CD/DVD
Library
Procedure for Closing the CD/DVD Library Door
●
Execute the automatic drive detection mode and connect the host
computer.
Procedure for Executing the Automatic Drive Detection Mode of
the CD/DVD Library
Procedure for Connecting the CD/DVD Library to the Host Com-
puter

PRECAUTIONS BEFORE USE

●
The MC-BL10U is a Blu-ray drive designed for use with the
JVC MC-8100LU/8200LU/8600LU "CD/DVD Library".
●
When installing this unit in a Library that is being used, please
read the instruction manual carefully.
●
The MC-BL10U cannot be operated on its own.
●
This unit cannot be used in combination with the following
models.
• CD-ROM Library : MC-1000 series/2000 series
• DVD-RAM Library: MC-7000 series
• CD/DVD Library : MC-8000 series
●
MC-BL10U cannot be used with drives other than MC-R434U.
●
For the compatible discs, see the Specifications on page E7.
E

INSTALLATION

CONNECTION
SETUP
EXECUTION OF AUTOMATIC
DRIVE DETECTION MODE.
●
In case of using MC-BL10U, MC-8200LU and MC-8600LU
have following limitation of the drive units due to the power
unit capacity.
* MC-8200LU/8600LU : max 5 drive units
e.g. MC-BL10U x 5
MC-BL10U x 1 and MC-R434U x 4
MC-BL10U x 0 and MC-R434U x 6
note : MC-8100LU doesn't have this limitation.
1. DANGER: Invisible laser radiation will occur if the unit is
open due to a failed or defective interlocking device.
2. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the unit; leave all servicing to
qualified service personnel.
Page E3, E4
Page E4, E5
Page E5
Page E6
