8. Option
15 V phantom power input 2
If you require 15 V phantom power, this can be
directly connected to the input-socket of input 2.
Factory-provided phantom power is deactivated
but, if required, may be activated by an internal
jumper.
In contrary 9V phantom power, if required, can
additionally be activated in input 1 by an internal
jumper.
Please note: For both alterations the device
must be opened, therefore only qualified service
personnel may carry out the modifications con-
cerning the de-/activating of phantom power.

10. Technical data

Inputs
Input 1 Combined XLR/jack socket
Line: 56 mV, 2.2 MΩ, unbalanced, switchable
9 V phantom power on ring (max. 40 mA)
Mic: 1.5 mV, 1200 Ω balanced, 4 kΩ unbalan-
ced, voice filter 300 Hz, switchable
48 V phantom power through 2x 6.8 kΩ
Piezo: 14 mV, 2.2 MΩ unbalanced,
switchable 9 V phantom power on ring
(max. 40 mA)
Piezo/Mic blender mode:
Piezo 15 mV, 2.2 MΩ, unbalanced, on jack/tip
or XLR/pin 2.
Uses input 2 internally.
Input 2 socket disabled.
Mic 3 mV, 660 Ω, unbalanced, 5 V phantom
power through 680 Ω,
on jack/ring or XLR/pin 3.
Input 2 Jack socket, unbalanced
Line: 30 mV, 90 kΩ
Piezo: 15 mV, 2.2 MΩ
Clip indicator Headroom 15 dB
Attack time 4 ms
Aux in Stereo cinch (RCA) sockets,
2x 71 mV, 22 kΩ
Effect return Jack, 210 mV, 24 kΩ
Outputs
Phones Jack, stereo (left and right connected), max.
20 V RMS, 470 Ω, max. 2x 100 mΩ. Does not
work with mono plugs!
Tuner Jack, 170 mV, 100 Ω

Insert

(In-/Output) Jack, stereo, 750 mΩ, 50 Ω
tip = send
Ring = return
sleeve = ground
Line out Jack, 750 mV, 100 Ω
Left/right out Jack, 750 mV, 50 Ω
Normally connected line out, prepared for
internal expansion modules
Effect send Jack, max. 340 mV (depending on
16
9. Insert
Insert-point
The insert connector is a stereo jack socket contai-
ning both output (send) and input (return) for a serial
effect loop (tip = send, ring = return).
Generally you will need an Y-cable (stereo / 2 x
mono) to connect the effect device to the insert
socket.
The direct signal path is interrupted while the insert
connector is plugged in.
"pan" setting), 50 Ω
DI out XLR socket, balanced, adjustable
55-280 mV, 200 Ω; switchable pre/post
effects and equalizer
Footswitch connectors
fs effect Jack, stereo
tip = built in effect
ring = external effect
sleeve = common
fs mute Jack, stereo
tip = mute input 1
ring = mute input 2
sleeve = common
Equalizer
Bass ±14 dB /60–400 Hz
narrow Q = 3
wide Q = 1
Middle ±6 dB / 800 Hz
Treble ±10 dB / 10 kHz
Analog singnal
processing Limiter, subsonic filter, fixed equalizer
Built-in effects 32-bit AER effects processor, 16 presets
Power amp Monolithic I.C., 60 W / 4 Ω
Limiter
threshold 50 W
Speaker
system 2-way with crossover
8" (20 cm) twin-cone fullrange speaker
(96 dB / 1 W / 1 m) 1" (25 mm) dome tweeter
Mains power AC 115/230 V (switchable),
50–60 Hz, max. 140 W
Mains fuse slow 2 A
General
Cabinet 15 mm (0.59") birch plywood
Finish waterbased acrylic, black spatter finish
Dimensions 330 x 260 x 235 mm
(13" x 10.24" x 9.25") W x H x D
Weight 7.8 kg (17 lbs)
