c) Indicator Light
Indicator Light Description
Blinks once every 5 seconds Transmitter power is ON and waiting to pair with device.
Stays on Transmitter is connected to device.
d) Reset Transmitter
You may need to reset the transmitter if it is not working as expected.
If you want to connect to a device other than the one(s) already paired you must
first perform a reset to clear all pairing data.
• To reset, press and hold the pairing button (4) for about 5 seconds until the indicator light (3)
flashes.
• Restart the transmitter and repeat the pairing process. See section "a) Pairing First Bluetooth
Device".

Troubleshooting

If you cannot hear sound on your Bluetooth device(s) check the following:
• If the indicator light is flashing it means the transmitter is not paired with your device.
• Check the transmitter power source. The indicator light should be on.
• Check that the transmitter audio input is connected to the correct device audio output.
• Check that the device power is on.
• Check that the device audio signal is being sent to the correct audio output (Refer to the
operating instructions of your playback device for more information).
• Check that the device volume is turned up or is not muted.
• Decrease distance between the transmitter and the playback device.
• Other devices using the same frequency (2.4 GHz, e.g. WLAN) may cause interference and
affect Bluetooth function and range.
If you cannot find a solution above, try resetting the transmitter and pairing the
device(s) again.

Care and Cleaning

• Disconnect the product from the mains before each cleaning.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a dry, fibre-free cloth.

Declaration of Conformity (DOC)

Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this
product conforms to the 2014/53/EU directive.
Click on the following link to read the full text of the EU declaration of conformity:
www.conrad.com/downloads
Select a language by clicking on a flag symbol and enter the product order number
in the search box. You can then download the EU declaration of conformity in PDF
format.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product in accordance
with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the
environment.

Technical Data

Input voltage / current ................... 5 V/DC via USB, max. 500 mA
Input type ...................................... Optical SPDIF (PCM only)
Codec support .............................. aptX
Bluetooth ...................................... v 3.0 + EDR, A2DP
Effective range .............................. < 10 m
Frequency range .......................... 2402 - 2480 MHz
Transmitter power ......................... -6 – 4 dBm
Digital audio format input .............. (32/24, 44.1/24, 48/24, 88.2/24, 96/24, 192/24) KHz / bits
Operating conditions ..................... 0 to 45 °C, 0 – 80 % relative humidity
Storage conditions ........................ -10 to 60 °C, 0 – 80 % relative humidity
Dimensions (L x W x H) ................ 70 x 35 x 18 mm
Length of USB cable ..................... approx. 30 cm
Weight .......................................... 28 g
low latency, SBC
®
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE. *1574806_v5_0518_02_fl01_m_4L
