Control Board

The Control Board offers several features: you can simply set the starting address or run the internal
programs. Browse through the menu by pressing Mode. You can change the selection by pressing Up or
Down. The functions provided are described in the following sections.
Setting the DMX Start Address:
Mode:
Add
Setting DMX Mode
Mode:
6ch (default setting)
Setting solid colors:
When the display shows C, you can select the desired solid color. Please see the following table.
Mode:
C
Setting internal programs:
When the display shows P, you can select the desired internal program, with or without sound control.
Please see following table.
Mode:
P
You can do without a controller as the device features a built-in microphone, which provides automatic sound
control.
Setting the sound sensitivity:
Mode:
S S-00 – S-99 (50=default)
Value:
1 - 512
Value:
4ch
Value:
C01
C02
C03
C04
C05
C06
C07
C08
C09
C10
C11
C12
C13
C14
C15
Value:
P01
P02
P03
P04
P05
P06
P07
P08
P09
Value:
Function:
Red
Green
Blue
Amber
Neon green
Magenta
Cyan
White
Dark salmon
Lime green
Light lavender
Medium yellow
Pink
Steel blue
Warm white
Function:
Endless loop in 7 colors,
change every 3 seconds
Endless loop in 7 colors,
fade every 3 seconds
Endless loop in 3 colors,
change every 3 seconds
Endless loop in 3 colors,
fade every 3 seconds
Endless loop in 7 colors,
via sound control
Endless loop in 3 colors,
via sound control
Endless loop in 15 colors,
change every 3 seconds
Endless loop in 15 colors,
fade every 3 seconds
Endless loop in 15 colors,
via sound control
23/26 00048513.DOC, Version 1.1
