Weatherdock easyTRX2 S Series Handbuch Seite 100

Parameter
Channel Bandwidth
Channel spacing
Modulation modes
Bit rate
RX sensitivity
Co-channel suppression
Adjacent channel suppression
Intermodulation ratio
Blocking
Environmental
Operating temperature
AIS software version
Protection class
Notifications
Extra equipment
Compass safe distance
Weatherdock AG
Value
25kHz
25kHz
25kHz GMSK (AIS, TX and RX)
25kHz AFSK (DSC, RX only)
9600 b/s ± 50 ppm (GMSK)
1200 b/s ± 30 ppm (FSK)
– 107dBm 25kHz
(Message error rate 20%)
10dB
70dB
65dB
84dB
IEC 60945
-25ºC to +55ºC
3.x.x
IEC 62287, IP54
Power supply "ON", hardware error, safety
messages, silent mode,
transmitting
receiving
CPA alert & AIS S.A.R.T. alert
Via button for Silent mode / Anchor alert,
via button for SRM, transmitting safety
message or silent mode.
Switch contact for external signal source for
CPA or AIS-SART signal. (200mA max. at
contiguous irregular input voltage of the
easyTRX2S unit)
0,8m
Sigmundstraße 180
Tel.: +49 911 376638 30
D-90431 Nürnberg
www.weatherdock.de
Page 100 of 108
