Installation instructions, for professionals only

6.1. Operating mode

DIP-Bank 1
Function selection switch 1 and 2
In the operating mode the following
settings are possible:
Function selec-
tion switch
Normal
Timer I/0
Normal: Switchable or dimmable infrared heater/infrared plate.
The dimming function of the infrared heater/infrared plate is activated via the infra-
controller, see 6.2. Operating type (infrared heater/infrared plate) on page 19.
Timer I/0 (On/Off): In the operating mode, On/Off switches the controls off after
the set On-time has elapsed and is not activated again.
Switchable infrared heater / infrared plate.
For additional settings, see 6.5. On-time (I/0 timer) on page 22 and Fig. 15:
Timer I/0 operating mode on page 23.
WORLD OF WELLNESS
1 2
OFF OFF
ON OFF
Fig. 9: Operating mode
p. 18/32
