Sensor Error Detection; Connections - Danfoss MBT 9110 Handbuch

OUTPUT
CURRENT OUTPUT
Signal range
Min. signal range
Updating time
Load resistance
Load stability

SENSOR ERROR DETECTION

Programmable
NAMUR NE43 Upscale
NAMUR NE43 Downscale
EEx approval MBT 9110, 084Z7441
KEMA 04ATEX1339
Max. amb. temperature for T4
Max. amb. temperature for T6
ATEX, applicable in zone
ATEX Installation Drawing No.
OBSERVED AUTHORITY REQUIREMENTS
STANDARD
EMC 2004/108/EF
ATEX 94/9/EC
Of span =

CONNECTIONS

© Danfoss | DCS (im) | 2017.07
Emission and immunity
4 – 20 mA
16 mA
135 ms
≤ (V - 8) / 0.023 [Ω]
supply
≤ ±0.01% of span / 100 Ω
3.5 – 23 mA
23 mA
3.5 mA
II 1 G Ex ia IIC T4 or T6
II 1 D Ex iaD
85 °C
60 °C
0, 1, 2, 20, 21 or 22
MBT 9110 084Z7441
EN 61326-1
EN 60079-0, EN 60079-11
EN 60079-15, EN 60079-26
EN 61241-0, EN 61241-11
Of the presently selected range
IC.PS.P40.A4.ML | 520B7737 | 5
