Gyro Sensitivity: The "CH 5" switch controls the gyro sensitivity. 40%
sensitivity is factory-adjusted which turned out to be the perfect ad-
justment for all flight modes. So, both switch positions are set to the
same value and you are not allowed to change this setting. The switch
position is irrelevant.
Although the helicopter was mounted, adjusted and tested ex works, it is necessary to check all functions of the mod-
el to exclude any damages that might have arisen during the transport. Before you start the function test, you have to
adjust the steering mode configuration. There are two options to choose from: Mode 1 and Mode 2. Mode 2 is the
default configuration. If you want to change the mode, see the included transmitter manual for detailed instructions.
Mode 2:
www.heli-professional.com

Control Test

The left stick controls collective pitch/throttle (climb/sink) and rud-
der/tail rotor pitch (left/right).
The right stick controls the swash plate movements, i.e. elevator
(forwards/backwards) and aileron/roll (left/right).
