Please note:
It is possible to operate the LED outdoor spotlight with rechargeable batteries instead of bat-
teries. However, due to the lower capacity of the rechargeable batteries and a lower voltage
(rechargeable battery = 1.2 V, battery = 1.5 V), operating time is much shorter. Moreover, the
rechargeable batteries are more temperature sensitive than batteries (e.g. in winter time).
We therefore recommend to use only high-quality batteries for operating the LED outdoor spot-
light.
• Push in the locking knob of the wall holder (keep pressed) and put the LED outdoor spotlight with the
correct orientation on the wall holder (PIR sensor facing down) until the locking knob clicks into place.
• Turn in again the screw, which was previously removed, at the bottom, so that the LED outdoor spotlight
is fixated on the wall holder.
• To activate the LED outdoor spotlight, switch it on with the toggle switch at the bottom (switch position
„ON"). The LED outdoor spotlight is now activated for a few seconds; then the light goes out and the LED
outdoor spotlight is ready for use.
The light is automatically switched on depending on the preset switching threshold for ambient
brightness. Please observe the information contained in the following two chapters.
Settings and Operation
When you turn the PIR sensor to the left while facing the PIR sensor, you will see two rotary
knobs. They are used to set the on-time and the brightness threshold to activate the light.
a) Setting the On-time (Rotary Knob with Time Symbol)
Use this knob to set the duration for the power-on time (a duration of 10 ± 5 seconds to 30 ± 10 seconds can
be set). Turning it to the left in a counter-clockwise direction will reduce the power-on time, while to the right
in a clockwise direction will extend the duration.
If the PIR sensor detects a heat change again in the detection range within the on-time cycle,
the power-on time will restart anew.
Only if no more heat changes are detected in the detection range during on-time will the LED
outdoor spotlight go out.
b) Setting the switching threshold for the ambient brightness (rotary knob with sun/
moon icon)
With this knob you can set the switching threshold for ambient brightness that enables the PIR sensor and
turns on the LED outdoor spotlight in case of a heat change in the detection range.
Turning the rotary knob counter-clockwise to the left, in the direction of the moon symbol, means the PIR sen-
sor is activated when it gets darker; turning it clockwise to the right, in direction of the sun symbol, activates
the motion detector in brighter conditions.
c) Alignment of the PIR Sensor
The horizontal detection angle of the PIR-Sensor is 130°, the vertical detection angle 60°.
By turning the PIR sensor to the left or to right, you can adjust the horizontal detection range according to
local circumstances.
An arrow marking on the front side of the PIR sensor indicates the centre of the detection angle.
If the arrow on the front side of the PIR sensor points towards the arrow of the LED outdoor
spotlight, the detection angle is centred.
d) Alignment of the Light Head
The light head can be rotated to the left or right and tilted up and down. In this way, you can set the area to
be illuminated perfectly.
e) Switching the LED outdoor spotlight on/off
There is a toggle switch at the bottom of the LED outdoor spotlight. It has the following functions:
• Switch position "ON" (switched on)
The LED outdoor spotlight is switched on. If the ambient brightness is under the value set with the cor-
responding rotary knob, the PIR sensor will be active. If in this case the PIR sensor detects a change in
temperature in the detection range (for e.g. when a person entered the detection range), the lights of the
LED outdoor spotlight will be activated for the time period set with the rotary knob.
If the PIR sensor detects a heat change again in the detection range within the on-time cycle,
the power-on time will restart anew.
Only if no more heat changes are detected in the detection range during on-time will the LED
outdoor spotlight go out.
• Switch position "OFF" (switched off)
The LED outdoor spotlight is deactivated.
This switch position can be used when you do not need the LED outdoor spotlight for a longer
period of time.

Functional Test

For a functional test for the switching threshold of ambient brightness turn the rotary knob all the way into
the direction of sun icon. The knob for the power-on time should be in the base position (turn in a counter-
clockwise direction all the way to the left until it stops).
Now cross the detection range. The light of the LED outdoor spotlight switches on, if the PIR sensor detects
a thermal change within the detection range.
If you stand still (and the PIR sensor no longer detects a thermal change), the light should go out after a
few seconds.

Care and Cleaning

• Never use abrasive cleaning agents, cleaning alcohol or other chemical solutions, since these could dam-
age the enclosure or even impair operation.
• Use a dry, lint-free cloth to clean the product.
Disposal
a) Product
Electronic devices are recyclable material and do not belong in the household waste. Dispose of
an unserviceable product in accordance with the relevant statutory regulations.
Remove any inserted batteries/rechargeable batteries and dispose of them separately from the
product.
b) Batteries/Rechargeable Batteries
As the end user, you are required by law (Battery Ordinance) to return all spent batteries/rechargeable bat-
teries; disposal of them in the household waste is prohibited.
Batteries/rechargeable batteries contain harmful materials and are labelled with the symbol
shown to indicate that disposal in the household waste is forbidden. The symbols of the critical
heavy metals are: Cd=cadmium, Hg=mercury, Pb=lead (the marking can be seen on the battery/
rechargeable battery, e.g. underneath the refuse bin symbol shown on the left).
You can return your used batteries/rechargeable batteries free of charge at the official collection points of
your community, in our stores, or at places where batteries or rechargeable batteries are sold.
You thereby fulfil your statutory obligations and contribute to the protection of the environment.

Technical Data

Operating voltage ................................. 4,5 V/DC (3 batteries type AA/Mignon)
Protection class .................................... III
Protection type ...................................... IP44
LED illuminant ...................................... 2 x 0.5 W
The light is permanently installed and cannot be replaced.
Luminous flux ....................................... 80 lm
Light colour ........................................... 5500 K (±500 K), cold white
Angle of light beam ............................... 120°
Swivel range of the light ....................... 25° upwards, 40° downwards
Rotating range of the light .................... 130° left, 190° to the right
Duty cycle ............................................. adjustable, 10 ±5 s.....30 ±10 s
PIR range ............................................. up to approx. 8 m (see chapter „PIR sensor function")
PIR detection angle .............................. 130° horizontal, 60° vertical
PIR rotation range ................................ ±130°
Operation/storage conditions ................ -20 °C to +40 °C
Dimensions ........................................... 66 x 109 x 176 mm (B x T x H)
Weight .................................................. 360 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2016 by Conrad Electronic SE. 1435591_V2_0716_02_VTP_m_en
