AXIS P33/-V Network Camera Series
Power LED
Green
Amber
Connectors and Buttons
For specifications and operating conditions, see page 13.
Note
Note that AXIS P3354 does not support audio or I/O functionality.
Network Connector
RJ45 Ethernet connector with Power over Ethernet (PoE).
NO TICE
TICE
NO
NO
TICE
Valid for AXIS P3354 and AXIS P3364–V:
The product shall be connected using a shielded network cable (STP). All cables connecting
the product to the network shall be intended for their specific use. Make sure that the
network devices are installed in accordance with the manufacturer's instructions. For
information about regulatory requirements, see Electromagnetic Compatibility (EMC) on
page 2.
NO TICE
TICE
NO
NO
TICE
Valid for AXIS P3365–V, AXIS P3367–V and P3384–V:
Due to local regulations or the environmental and electrical conditions in which the product
is to be used, a shielded network cable (STP) may be appropriate or required. All cables
connecting the product to the network and that are routed outdoors or in demanding
electrical environments shall be intended for their specific use. Make sure that the network
devices are installed in accordance with the manufacturer's instructions. For information
about regulatory requirements, see Electromagnetic Compatibility (EMC) on page 2.
I/O Connector
Use with external devices in combination with, for example, tampering alarms, motion detection,
event triggering, time lapse recording and alarm notifications. In addition to the 0 V DC reference
point and power (DC output), the I/O connector provides the interface to:
Digital output – For connecting external devices such as relays and LEDs. Connected
devices can be activated by the VAPIX® Application Programming Interface, output
buttons on the Live View page or by an Action Rule. The output will show as active
(shown under System Options > Ports & Devices) if the alarm device is activated.
Digital input – An alarm input for connecting devices that can toggle between an open
and closed circuit, for example: PIRs, door/window contacts, glass break detectors,
Indication
Normal operation.
Flashes green/amber during firmware upgrade.
12
