MULTY - Wireless weather station
10. Thermometer and hygrometer
10.1 Trend pointer
• The upper trend pointer on the display will show if the indoor temperature is
increasing, steady or decreasing.
• The lower trend pointer on the display will show if the outdoor temperature is
increasing, steady or decreasing.
10.2 Maximum/minimum function
• Press the UP button.
• MAX appears on the display.
• You can now get the highest value for the temperature and humidity for indoor
and outdoor. Press the UP button again.
• MIN appears on the display.
• You can now get the lowest value for the temperature and humidity for indoor
and outdoor. If you press and hold the UP button for 3 seconds, the values are
deleted and reset to the actual value.
• Press the UP button again to return to normal mode.
10.3 Setting of the temperature unit
• Press the DOWN button on the basic station to change between °C (Celsius) or °F
(Fahrenheit) as temperature unit.
10.4 Comfort level
• On the display appears a face symbol to indicate the comfort level of indoor cli-
mate.
Symbol Temperature
Dry
☺
Comfort 20...27°C
Wet
11. Additional outdoor transmitters
• For having more than one additional outdoor transmitter select with the 1/2/3
switch in the battery compartment of the outdoor transmitter for each single out-
door transmitter a different channel. The reception of the new transmitter will be
transmitted automatically to the basic station. Press and hold the CHANNEL but-
ton on the basic station or restart the basic station according to the manual.
• The outdoor values will be shown on the display of the basic station. If you have
installed more than one transmitter, press the CHANNEL button to change
between the outdoor transmitters.
• Once registered outdoor transmitters (channels), which are no longer needed, can
be deleted manually by pressing the CHANNEL button for three seconds. Once a
new outdoor transmitter is received, there will be another indicator.
11.1 Outdoor temperature alarm for channel 1 - 3
• Press and hold the DOWN button for three seconds in the normal mode.
• OFF (default) appears on the display.
• Press the CHANNEL button, to select the corresponding outdoor transmitter.
• Press the UP or DOWN button, to activate the outdoor temperature alarm (ON).
20
10:41 Uhr Seite 11
Humidity
<40%
40...70%
>70%
MULTY - Wireless weather station
• Press the MODE button.
• and 70 °C (default) or the last adjusted upper temperature limit appear on the
display.
• Press the DOWN button, to adjust the upper temperature limit.
• Confirm with the MODE button.
• and -50°C (default) or the last adjusted lower temperature limit appear on the
display.
• Press the UP button to adjust the lower temperature limit.
• Confirm with the MODE button.
• The alarm is activated. On the display appears
• Press and hold the DOWN button in normal mode for three seconds, to deactivate
the alarm function.
• Press the CHANNEL button, to select the corresponding outdoor transmitter.
• ON will be flashing. disappears.
• Press the UP or DOWN button.
• OFF appears on the display.
• The alarm function is deactivated.
• Press the MODE button three times, to return to normal mode.
11.2 Case of alarm
• In the case of an alarm a beep will sound at regular intervals.
• The corresponding symbol or and the set temperature will be flashing.
• Press and hold the DOWN button, to deactivate the alarm function.
• ON will be flashing.
• Press the CHANNEL button, to select the outdoor transmitter.
• Press the UP or DOWN button.
• OFF appears on the display.
• The alarm function is deactivated.
• Press the MODE button three times, to return to normal mode.
12. Positioning and fixing of basic station and the outdoor transmitter
• With the foldable leg at the back of the basic station, the basic station can be
placed onto any flat surface or wall mounted at the respective location by the
hanging hole at the back of the unit. Avoid the vicinity of any interfering field like
computer monitors or TV sets and solid metal objects.
• With the hanging hole at the back of the outdoor transmitter, the transmitter can
be wall mounted at the respective location. Choose a shady and dry position for
the outdoor transmitter. (Direct sunshine falsifies the measurement and continu-
ous humidity strains the electronic components needlessly).
• Check the transmission of the signal from the outdoor transmitter to the basic sta-
tion (transmission range of up to 80 m free field). Within ferro-concrete rooms
(basements, superstructures), the received signal is naturally weakened.
• If necessary choose another position for the outdoor transmitter and/or receiver.
13. Care and maintenance
• Clean the devices with a soft damp cloth. Do not use solvents or scouring agents.
• Remove the batteries if you do not use the devices for a long period of time.
• Keep the devices in a dry place.
13.1 Battery replacement
• As soon as the battery symbol appears on the display of the basic station beside
the outdoor temperature or on the display of the outdoor transmitter, change the
batteries of the outdoor transmitter.
.
