USER GUIDE (ENGLISH)

Box Contents

M-Track Plus
Software DVD
iLok 2
Support
For complete system requirements, compatibility information, and product registration, visit the support section of the M-Audio
website: www.m-audio.com/support.
Quick Start
Setup Scenario*
Digital
Computer
Cable Box**
Microphone
Headphones
External Effects Module
(e.g., compressor, reverb, etc.)
Notes:
When recording a guitar or bass with an active pickup, set the M-Track Plus's MIC/LINE / GUITAR SWITCH to "MIC/LINE."
If your instrument uses a passive pickup, set the switch to "GUITAR."
Do not use the MIC INPUT and GUITAR/LINE INPUT at the same time on one channel. This may overload the channel and
cause distortion.
Plug the M-Track Plus directly into your computer, and avoid using a USB hub. Hubs can interfere with the M-Track Plus's
audio and MIDI timing signals.
Recommended Installations
We highly recommend installing the following software applications:
Pro Tools Express: We've included Pro Tools Express with your M-Track Plus so you can get started making music with a
professional DAW right out of the box:
1. Insert the DVD into your computer's DVD drive. Double-click the DVD to view its contents. Locate, open, and follow
the installation instructions.
2. After activating Pro Tools Express and receiving the license, connect the included iLok 2 to a USB port on your
computer and transfer the license to it.
Connect the iLok 2 to your computer whenever you want to use Pro Tools Express. The software will launch
once it verifies the license on the iLok 2. (Visit www.avid.com to check for any available software updates.)
Ignite (www.airmusictech.com/getignite): We recommend downloading Ignite, a music creation tool designed by AIR Music
Technology to be easiest way to capture, build, and share musical ideas. Ignite works well on its own or as a writing companion
to the production capabilities of your software.
USB Cable
User Guide
Safety Instructions & Warranty Information booklet
Stereo System
Receiver***
STEREO 1
284
VOL: 28
Monitors
* Items not listed in Box Contents are
not included.
** Monitor audio sources connected to
M-Track Plus's S/PDIF IN by setting
the INPUT SELECTOR to "DIGITAL."
To monitor audio sources connected to
the MIC INPUTS or GUITAR / LINE
Guitar
INPUTS, switch it back to "ANALOG."
This way, you can leave your mics or
instruments connected to M-Track
Plus while listening to your TV's audio
over your connected monitors—or
leave M-Track Plus connected to your
media setup even while you record
your music.
*** If you do not have monitors, you
can connect M-Track Plus's S/PDIF
OUT to a stereo system receiver to
hear the audio through your home
speaker system.
3
