Hose U-bend Clip

The vacuum hose has a U-bend clip which creates a U-bend in the hose preventing water spillage when the vacuum is
switched off. If you need to remove the U-bend clip for any reason always ensure it is refitted correctly before you resume
operation (Fig 36-39).
36
38
Note: DO NOT push the vacuum hose onto the Floor-tool with the Floor-tool in the raised position.
Off-Aisle Cleaning Kit (Optional Extra Accessory ) 606182
40
Note: Return the hose to the floor-tool once finished using the off-aisle facility.
Machine Operation
37
39
Refit vacuum hose to the Floor-tool when finished.
The optional off-aisle cleaning kit gives added flexibility to the operator.
The kit can be used to clean hard to reach / inaccessible areas (Fig 40).
Remove the Vacuum hose from the Floor-tool and attach to the Off-aisle kit.
To operate the vacuum, press the Off-aisle vacuum button on the
control panel.
Pressing the Off-aisle Button again will switch the vacuum off (Fig 41).
