Technical Data - Graf PLATIN Montageanleitung

340 (Mini)
185
315
H
Tank
Art. No.
Weight
L
W
H
Htot*
* Htot = total height
mail@graf.info
www.graf.info
3.

Technical data

440 (Maxi)
600
185
265
Hges
Htot
L
1500 L 3000 L
390000 390001
82 kg 180 kg
2100 mm 2450 mm
1250 mm 2100 mm
700 mm 735 mm
1015 mm 1050 mm
14 / 39
600
185
B
5000 L 7500 L
390002 390005
250 kg 360 kg
2890 mm 3600 mm
2300 mm 2250 mm
950 mm 1250 mm
1265 mm 1565 mm
140
185
Hges
Htot
