Graf PLATIN Montageanleitung Seite 11

Installation and maintenance instructions for
PLATIN Rainwater Underground Tank
1500 L Order No. 390000
3000 L Order No. 390001
5000 L Order No. 390002
7500 L Order No. 390005
The points described in these
instructions must be observed
under all circumstances. All
warranty rights are invalidated
in the event of non-observance.
Separate
instructions are enclosed in the
transportation packaging for all
additional articles
from GRAF.
Missing instructions must be
requested from us immediately.
The tank must be checked for
any damage prior to insertion
into the trench
circumstances.
Missing instructions
downloaded on www.graf.info or
can be requested from GRAF.
mail@graf.info
www.graf.info
