3. Fig. B
Fit the rear cover cap (14) as a
stress-relieving device, then se-
cure the control panel (12) with
4 screws (15) and fit the cover
frame (16).
Truma offers side parts (17)
in eight different colors for
finishing the cover frames (16)
in a visually pleasing way. Please
ask your dealer.
4. Protect 12 V power supply
line (19) using provided 1 A fuse
(18). (Fuses not included in in-
dustrial bulk packaging.)
Red = plus
Blue = minus
When connecting directly to the
battery, always fuse the positive
and negative lead.
12
If necessary, the voltage supply
can be lengthened with an ex-
tension cord of 2 x 0.75 mm².
When using power supply
units, make sure that the
output voltage is between 11 V
and 15 V.
With the Truma transformer
connector (part no. 53110-01)
the remote indicator can also be
operated with 230 V. The trans-
former connector supplies
a 12 V alternating current with
low power. The two cables on
the transformer connector can
be connected in any order.
Only the remote indicator can be
powered over the transformer
plug (it is not possible to connect
additional 12 V devices).

Function check

The operation of the remote
indicator must be tested after
installation, as described in the
operating instructions.
The operating instructions are to
be handed over to the user.
