Assembling the remote
indicator's transmitter
Fig. A
Use the transmitter (5) to turn
off and remove the hexagon on
the visible indicator. Completely
remove any chips that may be
left behind.
Place the transmitter (5) onto the
visible indicator (4).
Lead the three-pole connection
cable (6) from the cylinder box
and connect it to the black plug
on the control panel cable.
Assembling EisEx
Due to the danger of fire,
never operate EisEx in the
uninstalled condition!
Check pocket hole at changeo-
ver valve or changeover regula-
tor system for soiling and clean
if necessary. Insert the heating
cartridge into the pocket hole
and fasten it in place with the
included screw.
Lead the two-pole connection
cable (2) from the cylinder box
and connect it to the white plug
on the control panel cable. Use
cable binders or something
similar to secure the cable onto
the regulator connection hose or
the gas pipe, thereby securing it
from sliding abrasion.

Electrical connection

1. Fig. B
Provide space for the control
panel (12) at an easily visible
location. Length of the connec-
tion cable 6 m. If required, a 5 m
extension cable is available
(part no. 34300-01).
If it is not possible to install
the control panel flush
with the surface, Truma can pro-
vide a surface-mounting frame
(11) on request, as a accessory
(part no. 40000-52600).
2. Drill two holes of 55 mm
diameter. Lead the ten-pole plug
on the control panel cable (13)
through the hole from the back
and connect it to the control
panel.
