Radio
Refer to this picture to identify the various parts of the device:
19
18
17
16
15. Built-in speaker Here is where the speaker is housed.
16. MENU button Press this button to enter the radio's MENU.
17. CALL/ button To send a CALL on the selected channel. If you keep it pressed for about 5 seconds,
the keypad lock is activated.
18. PTT (push to talk) The PTT key has a dual function, as it is composed by 2 parts: the larger and bigger
side of the PTT key, allowes the transceiver to send with high or low power (depending
on the setting of the menu); while the small PTT (Boost) allows the transceiver to
transmit always with high power.
19. VOLUME knob On/off switch for the device and adjusts VOLUME of reception.
20. ANTENNA Receives and transmits radio signals.
21. Accessory socket (under protective cover) To connect to external audio devices such as microphones,
chargers, etc. (2pin type)
EMG
22. button To activate the Emergency and the Manual Out of range functions.
23. ▲▼ buttons To change the setting within the MENU
24. Built-in microphone Here is where sound is picked up by the microphone.
14
EMG
CALL
MENU
20
21
22
23
24
15
