Technical Data

152mm X 165mm X
Size 178mm
(6" X 6.5" X 7.0")
Weight 1.2 kg (2.6lbs)
Minimum
Dispense 0.020 Seconds
Time
Input Voltage 24VDC
Rated Power 10W
Air Input 100 psi (6.9 bars) Max.
Pollution
II
Degree

Installation

I
Category
Altitude up to 2,000m
Indoor Use
(6,562ft)
Operating 0˚C to 50˚C (32˚F to
Temperature 122˚F)
4 Installation
Use 5 micron Filter –Regulator –Loctite 985397 or
equivalent for inlet air supply
1
2
5
4.1 10ml or 30ml syringe adapter attaches to Pulsed Air
Outlet (7) and syringe barrel.
Max.
Relative
Humidity
Air Output
Maximum
Dispense
Time
Vacuum
Timer
Cycle Mode
Timing
Repeat
Tolerance
Cycle Rate
LCD
Storage
Temperature
3
4
Fig. 4.1
6
80% for temperature up to
31˚C (87.8˚F) Decreasing
linearly to 50% relative
humility at 40˚C (104˚F)
0-100 psi (0-6.9 bars)
99.999 seconds
406mm (16") of Hg
0.020 - 99.999 seconds
Timed, Incremental, Manual
+/- 0.001%
600 cycles/min
16 X 2 display segments
-10˚C to 60˚C (14˚F to
140˚F)
Items Description
1 To Air Source
Air Filter –sold
2 separately
3 Power Adapter
Foot Switch
4
5 Syringe Adapter
