Fusion Panels - GYBE EVENT TENT Aufbauanleitung

EN ATTACHING FUSION PANELS
1
For attaching the Fusion Panels, two tents
are to be placed next to each other at about
6.5 feet distance.
One of the tents should already be firmly
fastened to the ground, for instance with the
water- or sandbags as described on page 9.
3
Pull the zipper around to the lower right
corner and fasten it at both corners with the
beltstraps.
24
2
Lay out the Fusion Panel next to the tents. The
starting point of the zipper is always located on
the left edge of a Fusion Panel.
The starting point of the tent-side zipper is just
under the roof panel, and has to be pulled up a
bit with the left hand (2a).
4
Now place the second tent as close as possible
to the first one. Attach the Fusion Panel, starting
once again from the lower left side (4a).
Fasten the corners with the beltstraps.
A
A
