SETTING UP YOUR EVENT TENT

1
Remove the tent from the transport
backpack. Unfold the rolled-up tent just
once in the middle.
18
A
B
2
Now fully unroll in both directions the
full-length part of the inflatable structure,
which has just been revealed.
3
Close all deflation valves (3a) and one of the
inflation valves, which you will find on the
underside of the strut.
Now fill the tent with either an electric or
hand pump, using the remaining inflation
valve (3b).
Please make sure that the pump tube is
firmly attached, and that it does not get
twisted.
Once the strut has been filled, the inflation
valve must always be closed with the
attached plug.
Further, be sure not to let the internal pressure
of the strut exceed 6 psi (0.4 bar).
The ideal pressure for the strut is between
4 and 5 psi (0.25 and 0.35 bar).
