Installation

Disconnect supply voltage!
Cut-off Relay 6415 is suitable for installation in, e.g., stand-
ard flush-mounted (in accordance with DIN 49037) or
surface-mounted junction boxes (e.g., Art. No. 2655 WS).
• When connecting, refer to the wiring examples in Fig. 1
and 2 and/or the connection diagram printed on the back
of the device.
• Always check the direction of travel of the blinds. If
necessary, replace the output or input contacts.
NOTE
Cut-off Relay 6415 is designed in such a way that, if
necessary, it can be installed behind the sensing element,
e.g., in a switch junction box.
In the case of Cut-off Relay 6415, a novel, stranded conduc-
tor has been used, consequently, connector sleeves are
not required.
