5. Installation eLLK 92..LED NIB;
eLLS 08... LED NIB
The respective national regulations as
well as the general rules of engineering
which apply to the installation and operation
of explosion protected apparatus, will have
to be observed!
Transport and storage of the luminaire is
permitted in original packing and specified
position only!
Note: When installing the light so as to
enable tilting along the longitudinal axis
(e.g. railing installations), it is recommended
to replace the cover of the central locking
device with the following version: ID no.
22216904000
Mind:
For handrail mounting (e.g. mounted at 45°)
we recommend replacing the existing cover
of the locking bolt with the version part no
22216904000.
5.1 Opening and closing the light fitting
– Turn the central locking device with a box
spanner (opening of the spanner SW 13)
through 90° to its lock-in position and fold
down the protective bowl, see fig. 3.
Caution: If an unsuitable tool is used,
frictional turning of the central locking
device can not be guaranteed and the
device may be damaged.
– Fit in and remove the protective bowl acc. to
fig. 5 and 6.
– The protective bowl can, at option, be hinged
on either side.
– To close the light fitting, press the protective
bowl tightly onto the luminaire housing and turn
the central locking device through 90°.
The integrity of the fitting may be
compromised if the fixing centres are not
correctly aligned, see fig. 9-110. When fixing
the mounting accessories onto the light
fitting, observe the max. depth of thread of
12 mm!
Do not use too long screws!
Installing the light output upwards additional
protection has to be assembled to avoid
permanent water accumulations at the protective
bowl gasket area.
Accessories for mounting:
See CCH/CEAG catalogue.
Explosion protected emergency light fittings
Series: eLLK(M)(S)92 LED 400(800) NIB
5.2

Mains connection

To open the connection box, turn the green
handle to its stop in the direction of arrow, then
pull it and fold down the flap (fig. 3 and 4).
For power connection, use cables with copper
conductor.
– Introduce the cable through the Ex cable entry
(fig. 4). Use both sealing inserts for cables from
8 to 12 mm Ø, and the outer sealing insert only
for cables from 12 to 17.5 mm Ø. Pay
attention to the proper fit of the sealing insert
remaining in the cable gland.
– Connect the conductors to the terminals
PE, N, L1, L, (L2, L3) in accordance with the
terminal marking (wiring diagrams, page 6).
Also tighten vacant terminals!
Mind: The charging conductor L and
the luminaire's mains connection must
always be connected to the same external
conductor of the mains supply!
Attention: In case of unused cable
entries, remove their protective cover and
close the entries with a blanking plug. When
closing the gland with a blanking plug,
always use both sealing inserts! When metal
cable entries are used, the protective caps
of the unused entries are to be removed
and the entries to be closed with certified
Ex blanking plugs!
5.3 Installation eLLM 92... LED NIB
The pole mounted light fitting is mounted and
installed in the following order:
– Unscrew the three recessed head screws in
the cover of the pole connecting compartment
(fig. 1, item 1).
– Open the connecting compartment by folding
down the cover (fig. 1, item 2).
– Pull the stay shackle of the cable entry socket
up to its stop and take off the cover plate
(fig. 1, item 3).
– Remove the cable entry sockets from the
guiding grooves in the connecting compart-
ment.
– Then the pole mounting tube or the tube of the
wall socket of 42 mm [ each (fig. 1, item 4) is
pushed home into the opening of the light fitting
(fig. 1, item 4a).
– Adjust the light fitting and screw down the
preassembled M 6 special screws (torque of
3.0 Nm, fig. 1, item 5).
– Introduce the cable through the tube and strip
the insulation to the required length.
– Introduce the cable through the Ex cable entry
(KLE) and tighten it with the pressure screw of
the cable entry.
– The complete support (with the cable being
introduced) is put into the guiding grooves of
the pole mounted light fitting (fig. 1, item 6).
– Lock the support with the stay shackle
(fig. 1, item 3).
– Insert the cable into the pull-relief and tighten it
(fig. 1, item 7).
– Then connect the cable in accordance with the
terminal marking.
EATON's Crouse-Hinds Business
If multi- or fine-wire conneting cables are used,
the wire ends will have to be handled in acc. with
the applicable national and international rules.
(e.g. use of sleeves for strands).
5.4 LED module inserting
As delivered, the LED module
(BVS 13 ATEX E018 U / IECEx BVS 13.0030 U)
is attached to the light fitting.
Use only approved Eaton / CEAG stock
items in stock!
Snap the module into the G13-sockets of the
light fitting, whereby a distinct clicking sound
can be heard (Fig. 2.8).
6.

Taking into operation

Prior to operation, check the light fitting
for its proper functioning and installation in
compliance with these operating instruc-
tions and other applicable regulations!
Only carry out insulation measurements
between PE and the external conductor L1
(L, L2, L3) as well as between PE and N.
– measuring voltage: max. 1 kV DC
– measuring current: max. 10 mA
Mind: There must no insulation meas-
urement be carried out between L and N,
since that would destroy the electronics
(mains input fuse in the VE unit).
– Then the luminaire will have to be closed. The
terminal compartment of the pole mounted light
fitting (eLLM 92..) is again to be covered with
the cover plate that was previously removed.
To that effect, pull up the stay shackle of the
cable entry socket (fig. 1, item 3) and clamp
down the cover plate and the cable entry
socket with the stay shackle. Again screw
down the cover of the terminal compartment
with the three recessed head screws.
– Switch on the mains voltage and then the light
fitting.
– Leave the light fitting switched on for at least
14 hours so that the battery will be recharged.
– After that, release a function test of the
emergency light connection, see 7.
Maintenance, function test.
7.

Maintenance

The national regulations applicable to
the maintenance, servicing and test of
apparatus for explosive atmospheres as
well as the general rules of engineering
will have to be observed (IEC/EN 60079-17
and IEC/EN 60079-19)!
