SYSTEMAUFBAU

Stativ-Varianten

Multi-axis Säulenständer
Objective lenses
0.45x EVL045
0.62x EVL062
1.0x EVL100
2
1.5x EVL150
EVB020
Fokuseinheit
EVF111
2.7x – 27x magnification super-long working distance lens (0.45x),
WD 176mm - supplied secondary ringlight lens to optimise illumination
3.7x – 37x magnification extra-long working distance lens (0.62x),
WD 128mm - supplied secondary ringlight lens to optimise illumination
6.0x – 60x magnification lens (1.0x), WD 75mm
9.0x – 90x high magnification lens (1.5x), WD 42mm
- supplied secondary ringlight lens to optimise illumination
Ergo-Stativ
mit Fokus
EVB010
Verschiebetisch
EVS120
Durchlichtbeleuchtung
EVS011
Objektive
