Cordless Extended Reach Hedge Trimmer 8570

Technical Specifications

Rated Voltage
No-load Speed n
0
Maximum cutting length
Maximum cutting diameter
Angle at which the motor can be set
Tool length
Working height
Weight with bar+chain
Sound Pressure Level (
EN ISO 10517)
Acoustic capacity level L
wA (20001/14/EG)
Vibration (
EN ISO 10517)
Mains battery charger
Mains voltage
Charging voltage / Charging current
Period of charging
Technical changes are reserved.
The specified vibration emissions value is measured in accordance with EN ISO 10517. This can be used for any
other hedge trimmer with the same design and type of power supply.
The specified vibration emissions value limits the working time. Stop working if you notice a tingling sensation or a
discolouration (white) of the fingers.
WARNING: When in operation, the tool's actual vibration emissions value can deviate from the specified value de-
pending on how the tool is used, as in the following examples or because it is used in another way:
- How the tool is being used and which materials are being cut.
- The tool is well maintained and in good working order. The correct accessories are being used and care has been
taken to make sure they are sharp and in good working order.
- How secure the hand grip is and whether anti-vibration accessories are being used.
- Whether the tool is being used in accordance with its design and as specified in these instructions.
- The tool can cause hand-arm vibration syndrome symptoms if it is not used properly.
WARNING: To make sure, an assessment should be made of the strain exerted when the tool is in use, for example
when the tool is switched off or is idling. This will make it possible to significantly reduce the strain exerted during the
entire time the tool is in use.
Minimise your risks if the tool vibrates.
Take care of the tool as specified in these instructions and make sure the tool is properly lubricated (if necessary).
If the temperature is 10°C or less, do not use the tools. Prepare a work schedule so that work is distributed over
several days when using tools that exert high vibrations.
Noise emission information in accordance with the German Product Safety Act (ProdSG) and the EC Machine Direc-
tive: the noise pressure level at the place of work can exceed 80 dB(A). In such cases the operator will require noise
protection (e.g. wearing of ear protectors).
Attention: Noise protection! Please observe the local regulations when operating your device.
24 V DC / 1.9 Ah / 45.6 Wh
2200 - 3000 min
400 mm
18 mm
0° to 135°
from 1.95 m to 2.35 m
up to 3.5 m
4.2 kg
82 dB(A)
95 dB(A)
<2.5 m/s
230 V~ / 50 Hz
25.2 V DC / 500 mA
approx 3 - 5 hour
Contact us at www.mantis.uk.com
-1
K = 2.5 dB
K = 2.6 dB
2 K = 1.5 m/s
2
