Parts

1. Blade
2. Transport guard
3. Adjusting knob (angle) for the cutter head
4. Threaded sleeve 1 (used to adjust the length of the shaft)
5. Telescoping shaft
6. Shoulder belt clasps
7. Shoulder belt
8. Wrapped handgrip
9. Lock for the ON/OFF switch
10. ON/OFF switch
11. Grip
12. Battery
13. Charging device for battery
14. Threaded sleeve 2 (used to secure the hedge trimmer to the shaft)
15. Adjusting speed controller (Power-Switch)
Cordless Extended Reach Hedge Trimmer Operator's Manual
