Start-up
During teach-in, please make sure you maintain a distance of at
least one meter between the Homematic devices and the Central
Control Unit.
To teach-in your device to the central control unit, proceed as follows:
• Open the "WebUI" user interface in your browser. Enter the URL
"http://Homematic-ccu2" in your browser. You will then be taken to the
homepage of your WebUI.
Fig. 5: WebUI homepage
• In order to activate the smoke alarm, turn the device in a clockwise
direction into the ceiling bracket until it clicks into place (see sec.
"Mounting the wireless smoke alarm" on page 47).
• Once the smoke alarm device is ready for operation, it can be taught-
in to the central control unit. During teach-in, please make sure you
maintain a distance of at least 1 m between the devices to avoid
interferences of the radio signal.
• Now activate teach-in mode of your Homematic Central Control Unit.
In the WebUI, please click the "Teach in devices" button on the right-
hand side of the screen.
Fig. 6: Screen shot teach-in device
42
• To activate teach-in mode, click "Start teach-in mode" in the next
window.
Fig. 7: Screen shot activate teach-in mode
• To activate the alarm mode of the smoke alarm device press and hold
down the operating button until the device LED starts flashing orange.
• The wireless smoke alarm will now be taught-in to the Homematic
Central Control Unit. During teach-in, the device LED will flash or-
ange. The device LED lights up green to indicate that teaching-in was
successful. The device LED lights up red to indicate that teaching-in
failed. In this case, please repeat the teach-in procedure.
• After a short time, the newly taught-in device will appear in the inbox
of your software interface. The button "Inbox (x new devices)" indi-
cates how many new devices have been taught-in successfully.
• If required, you can teach-in additional devices by repeating the steps
described above for each device.
• Now configure the newly taught-in devices in the inbox as described
in the next section.

6.1.3 Configuring newly taught-in devices

Once you have taught-in your device to the Homematic Central Control
Unit, it is moved to the inbox. Here, you must configure the device and
its associated channels in order to make them available for operating
