1. Safety instructions

Avoid any danger during maintenance and repair

• Only have repairs carried out by experts. Only use original accessories and
spare parts.

2. Device structure

When ordering spare parts, please always specify the appliance model and serial
number.
See Fig. A, B.
1 Device
2 Mounting plate
3 Sensor

3. Installation

Unpacking

1. Take all of the parts out of the packaging.
Scope of delivery:
• 1 device
• 1 mounting plate
• 4 screws
• 4 dowels
• 1 screw for the electric terminal cover

Installing the mounting plate

See Fig. C, D.
CAUTION
Unsuitable installation material!
Risk of injury caused by the device falling down.
Before installation:
1. Check if the screws and dowels supplied with the device are suitable for the sur-
face material.
1. Select a wall with a sturdy, weight-bearing surface.
4 Outlet opening
5 Air intake grille
6 Locking screw
