Parts List
No.
Description
1
Front support plate (boatstand)
2
Rear support plate (boatstand)
3
Side panel (boatstand)
4
Protective stand lining material
5
Keel / mast socket
6
Mast support reinforcement
7
Servo mount support
8
Hull
9
Bow reinforcement
10
Rudder bush reinforcement
11
Servo plate
12
Sail servo reinforcement
13
Jib trim servo reinforcement
14
Deck
15
Cockpit bulkhead
16
Rudder servo plate
17
Rudder servo reinforcement, large 1
18
Rudder servo reinforcement, small 1
19
Central bulkhead
20
Shroud reinforcement
21
Canopy latch reinforcement
22
Stern reinforcement
23
Stern side reinforcement
24
Captive nut
25
Central girder
26
Rudder bush
27
Rudder
28
Rudder servo
29
Rudder servo output arm
30
Tiller
31
Cable guide
32
Sheet guide
33
Fillister-head screw
34
Ring-screw
35
Washer
36
Sail-setting servo
37
Jib trim servo
38
Switch
39
Sail-setting lever
40
Pulley block
41
Fillister-head screw
42
Jib sheet
43
Washer
44
Mainsail sheet
45
Rudder steering cable
46
Tensioner
47
Turnbuckle
48
Keel
49
Keel adaptor set
50
Keel ballast bulb
51
Retaining pin
52
Keel bulb fairing
53
Retaining nut
54
Gasket
55
Canopy
56
Mast
57
Mast sleeve
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Keine Haftung für Druckfehler. Technische Änderungen vorbehalten! No liability for printing errors. We reserve the right to introduce
modifications. Sous réserve de modifications! Nous ne sommes pas responsables d'éventuelles erreurs d'impression!
No. off Material
1
Plywood
1
Plywood
4
Plywood
1
Self-adhesive foam tape
2
ABS
2
Plywood
2
Plywood
1
ABS
1
Plywood
2
Plywood
1
Plywood
2
Plywood
1
Plywood
1
ABS
1
Plywood
1
Plywood
Plywood
Plywood
1
Plywood
2
Plywood
4
Plywood
1
Plywood
2
Plywood
4
Metal
1
Spruce strip
1
Brass tube
1
Plastic
1
Order No. 5125.LOSE
2
Order No. 3941.50
1
Plastic
2
Snake inner sleeve
2
Plastic
14
Stainless steel
4
Nickel-plated brass
5
Nickel-plated brass
1
Order No. 4103.LOSE
1
Order No. 5125.LOSE
1
Order No. 3934.1
1
Plastic
2
Plastic
2
Stainless steel
1
Polyester cord
3
Nickel-plated brass
1
Polyester cord
2
Polyester cord
9
Plastic
4
Plastic
1
Plastic
4
Plastic
1
Lead (TOXIC !)
2
Steel
2
ABS
1
Nickel-plated brass
1
Rubber cord
1
ABS
1
CFRP tube
1
Aluminium tube
Size in mm
4 mm, laser-cut
4 mm, laser-cut
4 mm, laser-cut
Cut lengths to suit
Vac.-moulded,
CNC-trimmed
2 mm, laser-cut
2 mm, laser-cut
Vac.-moulded,
CNC-trimmed
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
Vac.-moulded,
CNC-trimmed
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
M2
3 x 8 x 210 mm
4 Ø x 3.1 Ø x 30 mm
Ready made
Ready made
Ready made
Ready made
2 Ø x 0.8 x 15 mm
Ready made
2.2 Ø x 6.5 mm
3.8 Ø x 1.5 Ø x 11 mm
4.5 Ø x 2.2 Ø x 0.5 mm
Ready made
Ready made
Ready made
Ready made
Ready made
2.2 Ø x 9.5 mm
0.4 Ø x 500 mm
Ready made
0.4 Ø x 500 mm
0.4 Ø x 300 mm
Ready made
Ready made
Ready made
Ready made
Ready made
1.5 Ø x 15 mm
Vac.-moulded
M2.5
2.5 mm Ø, overlength
Vac.-moulded, CNC- trimmed
5 Ø x 4 Ø x 850 mm
6 Ø x 5 Ø x 115 mm
#0060376
03/2009
