Yakima LockNLoad Pre-Assembled Platform Bedienungsanleitung

8005076 8005077
Platform Platform
!
1530 x
1250 mm 1390 mm
L x W
100 kg
DYNAMIC
220 lbs 220 lbs
272 kg 272 kg
STATIC
600 lbs 600 lbs
• LOAD = WEIGHT OF PLATFORM or BARS + MOUNTING SYSTEM + ACCESSORIES + CARGO
• PLEASE REFER TO VEHICLE MANUFACTURER SPECIFICATIONS FOR MAX
ROOF LOAD CAPACITY OF VEHICLE. THE LOWEST LOAD RATING APPLIES.
• OFFROAD RATING: SCAN QR CODE FOR LOCKNLOAD LOAD RATING GUIDE.
REDUCTIONS MAY APPLY.
• Always refer to our website for the latest version of instructions.
• Please read instructions carefully before installation.
• Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged.
• Clean your vehicle roof prior to fitting the LockNLoad Platform.
• Images throughout show a 7 Slat Platform. Please note other Platforms will have differing
amounts of slats and hardware.
• Place these instructions in the vehicle's glove box after installation is complete.
