OPERATION AND FUNCTIONS
Operation
1. Open the dust cover.
2. Place a record on the turntable platter.
3. Set the speed selector to the correct speed:
A. 33 rpm for 12-inch (30.48 cm) records (default).
B. 45 rpm for 7-inch (17.78 cm) records.
4. Remove the stylus guard.
5. Unlock and lift the tonearm using the lever.
6. Move the tonearm to the desired position on the record. The platter starts rotating automatically.
7. Press Play/Pause to stop or resume playback. The turntable stops automatically at the end of playback.
8. To disable auto stop, press the Auto Stop button. Use this only if playback stops before the record ends.
9. When playback is complete, raise the tonearm and return it to the rest. Lock the tonearm.
Always attach the stylus protector when moving, installing, or cleaning the unit.
Use the 45 rpm adapter for 7-inch records.
10 BT Receiver
1.1 Activate BT on your mobile device (refer to its user instructions).
1.2 Press the MODE/POWER switch to power on the unit.
Press repeatedly to select Bluetooth mode. The blue LED flashes to indicate pairing mode.
1.3 On your mobile device, search for "Ladero."
1.4 Select "Ladero" to pair. Enter 0000.
When paired, the blue LED remains solid.
1.5 Play audio from the mobile device.
Use the Volume/Pair control to pause or resume playback.
1.6 To disconnect, press and hold the Volume/Pair control until the "disconnected" voice prompt is heard. Press again to reconnect.
BT Transmitter
2.1 The BT transmitter operates only in PHONO and AUX IN modes.
2.2 Press the MODE/POWER switch to power on the unit.
Press repeatedly to select Turntable mode (default: 33 rpm, yellow indicator).
2.3 Follow the steps in the Turntable Operation section to start playback.
2.4 Set BT Transmission to ON. The transmitter enters pairing mode automatically.
If pairing fails within 2 minutes, ensure the external device is powered on, BT is enabled, and not connected to another device.
2.5 Set BT Transmission to OFF to stop audio transmission.

Automatic Connection

After initial pairing, the unit reconnects automatically to the last paired device when powered on and BT is enabled on the
device.
AUX IN Mode
3.1 Press the MODE/POWER switch to power on the unit.
Press repeatedly to select AUX IN mode (green LED).
3.2 Connect a 3.5 mm AUX cable from the line-out jack of your external audio source (e.g. MP3 player) to the
jack.
3.3 Start playback from the external device.
RCA OUT
4.1 Connect the RCA OUT jacks on the rear panel to an external audio amplifier using an RCA cable.
4.2 Set the Speaker Switch to OFF to disable the built-in speakers.

Automatic Standby

The unit enters standby mode automatically when:
• No buttons are pressed for 10 minutes, or
• No audio signal is received for 10 minutes from a connected device.
11/12 Power / Mode Selection
• Press the POWER/MODE switch to turn the unit on.
• Press repeatedly to select mode:
• TT mode – Yellow indicator
• BT mode – Blue indicator
• AUX mode – Green indicator
• Press and hold the POWER/MODE switch to enter standby (Red indicator).
13 Audio Controls
14 Bass Control – Turn the Bass knob to adjust low frequencies.
15 Treble Control – Turn the Treble knob to adjust high frequencies.
16 Volume Control – Turn the Volume knob to adjust sound level.
9
Speaker on/o
AUX in
Line out
L R
AUX in
AUX IN
Speaker on/o
Line out
L R
