Bestimmungsgemäße Verwendung Vielen Dank für den Kauf des XciteRC Hotbee 3D Quadrocopter. Die vorliegende Bedienungsanleitung ent- hält wichtige Hinweise für den Betrieb Ihres neuen Modells. Lesen Sie deshalb, bevor Sie das Modell in Betrieb nehmen, alle Anweisungen dieser Bedienungsanleitung vollständig durch, damit Sie Ihr Modell gefahrlos betreiben können.
Die folgenden Sicherheitshinweise müssen unbedingt beachtet werden. Für Sach-, Personen- oder Folge- schäden, die durch unsachgemäße Handhabung oder Nichtbeachtung der Sicherheitshinweise entstehen, übernimmt die XciteRC Modellbau GmbH & Co. KG keine Haftung. In diesen Fällen erlischt die Gewähr- leistung. Bewegen Sie Ihr Modell immer mit größter Vorsicht und Verantwortung, ansonsten kann es zu Schäden an fremden Eigentum oder gar Personenschäden kommen.
Lithium-Akku längere Zeit gelagert, kann er beschädigt werden. Die Firma XciteRC Modellbau GmbH & Co. KG kann den korrekten Umgang mit den von Ihnen verwendeten Akkus bzw. Batterien nicht überwachen, daher wird die Gewährleistung bei falscher Ladung oder Entladung ausgeschlossen.
3D Quadrocopter zeigt dabei zum Pilot und sein Kopf vorwärts (vom Pilot weg). Die linke Hand des Pilot ist die linke Seite und die rechte Hand die rechte Seite des HotBee 3D Quadrocopters. Der Kopf ist vorwärts und das Heck rückwärts gerichtet. Die Richtungen, in welche sich der Rumpf bewegt, ist in der folgenden...
• Ziehen Sie den Gashebel am Sender ganz nach hinten. • Schalten Sie den Sender ein. • Installieren Sie den Akkupack im Rumpf im entsprechenden Schacht. • Verbinden Sie die Stromversorgung des Empfängers mit dem Akku. 15000000 XciteRC Hotbee 3D Quadrocopter...
4. Wenn der Höhenruder-Knüppel nach vorne 3. Wenn der Seitenruder-Knüppel nach links oder oder hinten bewegt wird, fliegt der Helikopter vor- rechts bewegt wird, bewegt sich die Nase des oder rückwärts. Helikopters nach links oder rechts. 15000000 XciteRC Hotbee 3D Quadrocopter...
Seite 9
Erfahrung eingestellt werden. Die normale Einstellung beträgt 100%. • Steuern des Gashebels: Wenn der HotBee 3D beginnt aus der normalen Fluglage zu rollen, muss der Gashebel langsam nach hinten gezogen werden. Drücken Sie den Gashebel nach vorne, wenn das Modell bei der Rolle nach oben steigt.
Rotorblätter im Uhrzeigersinn sowie die linken vorderen und die rechten hinteren Rotor- blätter gegen den Uhrzeigersinn. • Sie können die Trimmungen im Sender (ausgenommen Gas) einstellen, wenn der Quadrocopter nicht stabil in der Luft steht. 15000000 XciteRC Hotbee 3D Quadrocopter...
56600003 15000008 15000001 15000001 15000007 15000005 15000005 Technische Daten Länge 127,7 mm Höhe 36 mm Gewicht 35 g Rotorblattdurchmesser 56 mm Gesamtdurchmesser 176 mm Akku 3,7 V 250 mAh 15C Flugzeit 6 bis 7 min. 15000000 XciteRC Hotbee 3D Quadrocopter...
Sie es - bevor Sie es benutzt haben - an Ihren Fachhändler oder an uns zurück und wir werden Ihnen Ersatz liefern. In Problemfällen oder bei Fragen wenden Sie sich bitte an Ihren Fachhändler oder: XciteRC Modellbau GmbH & Co. KG - Service, Autenbachstrasse 12, D-73035 Göppingen, Tel. +49 7161 40 799 50 Email: service@xciterc.de Ersatzteile können Sie entweder im Fachhandel oder online unter http://www.XciteRC.de/ beziehen.
Diese durchgekreuzte Mülltonne bedeutet, dass Sie Batterien und Akkus nicht im Hausmüll entsorgen dür- fen. Unter diesen Zeichen finden Sie zusätzlich nachstehende Symbole mit folgender Bedeutung: Cd = Cadmium Pb = Blei Hg = Quecksilber Li = Lithium Li-Po 15000000 XciteRC Hotbee 3D Quadrocopter...
All rights reserved. Intended Usage The XciteRC Hotbee 3D Quadrocopter is an electrically driven ready to fly RC helicopter including motor and speed controller. The control is wireless with an optional available 2.4 GHz transmitter. The model may only be operated on a suitable and sufficiently indoor room without obstacles. An operation outdoor is not recommended.
The following safety instructions must be strictly observed. For property damage, personal injury or conse- quential damage caused by improper use or non-observance of the safety instructions the XciteRC Modell- bau GmbH & Co. KG accepts no liability. In these cases, the warranty becomes void.
The XciteRC Modellbau GmbH & Co. KG cannot monitor the proper use of the battery or batteries you use, therefore, the warranty is excluded due to incorrect charging or discharging.
(front of pilot). The left hand of pilot Is the left side of Hotbee 3D Quadrocopter, the right hand of pilot Is the right side of Hotbee 3D Quadrocopter. Its head is to the front and its tail boom is to the back.
• Pull down the throttle stick to the lowest position. • Turn on the power of transmitter. • Install the battery pack in the battery compartment. • Connect the power cable of to receive signal from transmitter. 15000000 XciteRC Hotbee 3D Quadrocopter...
3. When moving the rudder stick left or right, the 4. When moving the elevator stick up or down, head of helicopter accordingly flies left or right. the helicopter accordingly flies forward or back- ward. 15000000 XciteRC Hotbee 3D Quadrocopter...
The default selling is 100%. • Practice of throttle slick: when the Hotbee 3D roll from normal status,the throttle stick need to be pulled • down slowly; push up the throttle when it exchanged normal status to roll. Please adjust according •...
• The front propellers are in orange color while the rear propellers are in black • After connecting the power of the Hotbee 3D, left rear / right front blades rotate clockwise, left front / right rear blades rotate counterclockwise.
Overall length 127.7 mm Overall height 36 mm All-up weight 35 g Main rotor blade Dia 56 mm Overall rotation Dia 176 mm Battery 3.7 V 250 mAh 15C Flight time 6 to 7 min. 15000000 XciteRC Hotbee 3D Quadrocopter...
Some parts are available as spares. If a part is defective or worn, you can identify it with the help of the exploded view. In case of problems or questions, please contact your dealer or: XciteRC Modellbau GmbH & Co. KG - Service, Autenbachstrasse 12, D-73035 Göppingen, Phone +49 7161 40 799 50 Email: service@xciterc.de Spare parts you may order in your local hobby shop or online at http://www.XciteRC.de/...
This crossed-out bin means that you must not dispose of batteries with household waste. Among these characters, see also the following symbols have the following meanings: • Cd = cadmium • Pb = plumbium • Hg = mercury • Li = lithium Li-Po 15000000 XciteRC Hotbee 3D Quadrocopter...
Conservez le pour votre lecture mais aussi remettez cette documentation à tierce personne si vous décidez de prêter ou vendre le XciteRC Hotbee 3D Quadrocopter. Notre garantie ne couvrira aucun dégât ou mauvais fonctionnement en cas de non-respect du mode d’emploi et des consignes de sécurité.
Consignes de sécurité CONSIGNES DE SECURITE Ces indications doivent être respectées impérativement. La XciteRC Modellbau GmbH&Co.KG décline toute responsabilité en cas de dommages aux personnes et/ou à autre matériel suite à une utilisation non conforme ou suite au non-respect des consignes de sécurité. Dans ces cas, la garantie ne s’applique pas.
La société XciteRC Modelbau GmbH & Co.KG ne peut pas contrôler la manipulation des accus faite par l’utilisateur et de ce fait, ne peut pas être tenue responsable d’une mauvaise opération de chargement ou déchargement.
Pour une meilleure compréhension de cette notice, nous allons définir les différentes directions. L’arrière du Quadrocoptère HotBee 3D est dans ce cas toujours face au pilote et le nez de l’appareil est vers l’avant. La main gauche du pilote correspond au coté gauche du Quadrocoptère HotBee 3D et la main droite, au coté...
• Mettez le manche de commande des gaz de l’émetteur complètement vers l’arrière. • Allumez l’émetteur. • Mettez l’accu en place dans la cellule, dans le logement correspondant. • Branchez l’alimentation du récepteur sur l’accu. 15000000 XciteRC Hotbee 3D Quadrocopter...
Seite 33
Le réglage normal est de 100%. • Commande des gaz: Lorsque le HotBee 3D entame des tonneaux en partant d’une position de vol normale, il faut tirer doucement le manche de commande des gaz vers l’arrière. Poussez le manche de commande des gaz vers l’avant lorsque le modèle a tendance à...
• Si le Quadrocoptère ne tient pas un stationnaire stable, vous pouvez régler cela avec les trims de l’émet- teur (à l’exception des gaz). 15000000 XciteRC Hotbee 3D Quadrocopter...
Caractéristiques techniques de l’hélicoptère Longueur 127.7 mm Hauteur 36 mm Poids 35 g Diamètre rotor 56 mm Diamètre rotor total 176 mm Caractéristiques accu 3.7 V 250 mAh 15C Temps de vol 6 à 7 min. 15000000 XciteRC Hotbee 3D Quadrocopter...
éclaté pour l’identifier et la commander. En cas de problème ou de questions consultez votre concessionnaire. XciteRC Modellbau GmbH & Co. KG - Service, Autenbachstrasse 12, D-73035 Göppingen, Tel. +49 7161 40 799 50 Email: service@xciterc.de Vous trouverez les pièces détachées chez votre concessionnaire ou online sur http://www.XciteRC.de/...
