S+S REGELTECHNIK RHEASGARD PLGF-Modbus Betriebs-, Montage- Und Installationsanleitung Seite 12

G
®
RHEASGARD PLGF-Modbus ⁄ PLGFV-Modbus
Schematic diagram
sb
LEDs
Plug for
display
Schematic diagram
sb offset
LEDs
Plug for
display
Connecting diagram
1
2
3
4
5
DIP A
ON
1 2 3 4 5 6 7 8
address
ON DIP B
1 2
1 2 3 4 5 6
mode
1 2
ON DIP A
1 2 3 4 5 6 7 8
address
DIP B
ON
1 2
1 2 3 4 5 6
mode
1 2
+UB 24V AC/DC
–UB GND
A
B
Shield
PLGF - Modbus Pin assignment
(M12)
zero
set
3 4 5
3 4 5
Plug for
display
PLGFV - Modbus
zero
set
3 4 5
3 4 5
PLGF - Modbus
PLGFV - Modbus
12
MALE
2
3 1
5
4
ON
sb offset
1 2 3 4 5 6 7 8
address
1
+UB
ON DIP B
2
Modbus A
1 2 3 4 5 6
mode
3
–UB GND
4
Modbus B
LEDs
5
Shield
SET potentiometer
sb = start-up suppression (min. 0 s ... max. 120 s)
offset = temperature (± 5K)
LEDs
(on = active)
sb = start- up suppression
ok = error-free protocol received
err. = faulty protocol or checksum
Pushbutton
zero ⁄ set:
Hold down for 2 s → activate menu on display
(display versions)
Hold down for 10 s → set zero (0 m ⁄ s)
(sb LED flashes during process and turns off
when zero is set)
up ⁄ down (display versions):
When the menu is activated (2 s hold down of zero ⁄
set button), you can change between 'Flow' (flow speed)
and 'Vol' (volume rate). When 'Vol' is selected
→ enter surface area in cm² (up/down)
→ zero ⁄ set button
→ enter unit (up ⁄ down)
→ zero ⁄ set button
Rev. Data - V12
xx - Modbus
FEMALE
2
1 3
5
4
zero
DIP A
set
1 2 3 4 5
1 2 3 4 5
